HYGRASGARD
Function 06 Write Single Register & Function 16 Write Multiple Register
Register Parameter (LEDs)
4x0025 LED 1 colour register
4x0026 LED 1 colour register
4x0027 LED 1 colour register
4x0028 LED 2 colour register
4x0029 LED 2 colour register
4x0030 LED 2 colour register
LED 3 colour register
4x0031
4x0032 LED 3 colour register
4x0033 LED 3 colour register
4x0034 LED 4 colour register
4x0035 LED 4 colour register
4x0036 LED 4 colour register
4x0037 LED 5 colour register
4x0038 LED 5 colour register
4x0039 LED 5 colour register
Function 08 Diagnostics
The following sub function codes are supported
Sub Function
Parameter
Code
00 Echo of transmission data
(Loopback)
01 Restart Modbus
(Reset listen-only mode)
04 Activation listen-only mode
10 Delete counter
11 Counter bus telegrams
12 Counter communication errors
(Parity, CRC, frame errors, etc.)
13 Counter exception telegrams
14 Counter slave telegrams
15 Counter telegrams without answer
Function 17 Report Slave ID
Composition of answer telegram
Byte No. Parameter
00 Number of bytes
01 Slave ID (device type)
02 Slave ID (device class)
03 Status
04 Version number (release)
05 Version number (version)
06 Version number (index)
®
RFTF - Modbus | Telegrams
Red
Green
Blue
Red
Green
Blue
Red
Green
Blue
Red
Green
Blue
Red
Green
Blue
Data Type
Data Type Answer
Echo data
Echo telegram
No answer
Echo telegram
Unsigned 16 Bit All valid bus telegrams
Unsigned 16 Bit Faulty bus telegrams
Unsigned 16 Bit Error counter
Unsigned 16 Bit Slave telegrams
Unsigned 16 Bit Broadcast messages (address 0)
Data Type Answer
Unsigned 8 Bit 6
Unsigned 8 Bit 11 = HYGRASGARD
Unsigned 8 Bit 20 = HYGRASGARD
Unsigned 8 Bit 255 = RUN, 0 = STOP
Unsigned 8 Bit 1...9
Unsigned 8 Bit 1...99
Unsigned 8 Bit 1
28
Value Range
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
0...63
®
MODBUS
® / HYGRASREG ®
