Features

Front Panel

1. Display: Shows the module's current settings
and functions.
2. Song/Pattern: In Normal Mode, press this
button to enter the Song Menu, where you
can select a song or adjust song-related
settings. In Learning Mode, press this button
to enter the Pattern Menu, where you can
select a pattern (full kit plus accompaniment)
to play along to or adjust pattern-related
settings.
Note: The LEDs above and below this
button indicate whether the module is in
Normal Mode
respectively.
3. Kit/Rhythm: In Normal Mode, press this
button to enter the Kit Menu, where you can
select a kit or adjust kit-related settings. In
Learning Mode, press this button to select a
rhythm (full kit) to play along to or adjust
pattern-related settings.
4. Voice/Beat: In Normal Mode, press this button to enter the Voice Menu, where you can select a
voice (drum sound) or adjust voice-related settings. In Learning Mode, press this button to
select a beat (snare drum only) to play along to or adjust pattern-related settings.
5. Page/Select: Press this button to cycle through the available settings for the current
mode/menu. Press and hold this button for one second to switch the three buttons above it
between Normal Mode and Learning Mode.
6. Volume: Adjusts the output volume of the Main Out and Phones.
7. Start/Stop: Press this to start/stop playback or recording.
8. Save: Press this to save your current kit settings.
9. </>: Use these arrow buttons to change the value of the setting shown in the display. (Usually,
this adjusts numerical values, such as kit numbers or effects levels.)
10. Click: Press this to turn the metronome ("click track") on/off. See the
section for more information.
11. Drum Off: When this button is on, its LED will be lit and the pre-recorded drum part will be
muted so you can hear only your performance and any accompaniment (backing music). Press it
again to hear the pre-recorded drum part. (This button will automatically be on while recording.)
12. Record: Press this button once to record-arm the module. Its LED will flash. To start recording,
press Start/Stop or hit a pad. When recording, its LED will light solid. (To stop recording, press
Start/Stop again.) See the
13. Tempo: Press this to show the current tempo in BPM (beats per minute) in the display. Use the
< or > buttons to change the tempo.
14. Utility: Press this button to access advanced settings for the pads as well as the module's MIDI
settings. See the
15. Play/Practice: In Normal Mode, press this button to hear a recorded performance. In Learning
Mode, press this button to start playing the beat, rhythm, or pattern; you can then play along to
it without being scored. Press and hold this button for 2 seconds to hear the playback of your
practice (every practice is automatically recorded). Press it again to stop playback.
16. Pad Select Buttons: Press these buttons to preview the voices (drum sounds) used for each
part of the kit, represented by the buttons. (After pressing the Snare button or any of the Tom
buttons, you can press the Rim button to hear the voice used as the rim sound of that drum.)
4
or Learning
Recording
Adjusting Utility Settings
Mode,
section for more information.
section for more information.
Adjusting the Metronome
