Component list
1 Chuck
2 Variable clutch
Gear control
3
4 Forward, reverse rotation and lock control
5 On/off switch with variable speed control
6 Battery pack latch
7 LED light
Battery pack *
8
9 Auxiliary handle *
10 Magnetic tray
Screw driver bit
11
* Not all the accessories illustrated or described are included in
standard delivery.
All manuals and user guides at all-guides.com
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
5
Technical data
Model No. WU152PT WU153PT WU157PT WU158PT
Rated voltage 12V
Rated no load speed
Number of clutch
position
Max torque 30N.m
Chuck capacity 10mm
Steel 10mm
Max. Drilling
capacity Wood 28mm
Machine weight 1.8kg
Model No. WU164PT
Rated voltage 18V
Rated no load speed 0-400/0-1300/min
No load impact
-
frequency
Number of clutch
21+1
position
Max torque 55N.m
Chuck capacity 13mm
Steel 13mm
Max.
Drilling Wood 38mm
capacity
Masonry -
Machine weight 2.4kg
12V 14.4V 14.4V
0-400/0-1300/min
21+1
30N.m 35N.m 35N.m
13mm 10mm 13mm
13mm 10mm 13mm
30mm 32mm 35mm
1.8kg 2.0kg 2.0kg
WU365PT WU367PT
14.4V 18V
0-400/0-1300/min
0-6400/0-20800 /min
20+1+1
50N.m 60N.m
13mm 13mm
13mm 13mm
38mm 38mm
16mm 16mm
2.5kg 2.7kg
