Electric fireplace Use instructions
Before use
Remove the fireplace from the box.
Remove all packaging and wrapping material before mounting and operating.
Package Contents
Electric Fireplace
Front Panel
Pebble Pack
Anchor bracket (for wall installation)
Installation Components Pack Containing:
Screws and Wall Anchors
Support bracket
Remote Control
Instruction Manual
Installation
Note: this fireplace is not equipped with any support for free-standing installation.
Warning: for correct installation and mounting of the fireplace, please contact specialized technical
personnel
This appliance is exclusively designed to be wall mounted at a minimum height of 30 cm from the floor (measured
from the bottom side of the glass panel), and at a minimum distance of 100 cm from the ceiling (measured from
the top side of the glass panel).
The mounting kit provided with the appliance includes:
6 screws for wall support and anchor brackets
6 wall anchors for mounting of anchor bracket
2 small screws for fastening of support bracket to the fireplace
1 wall anchor bracket
1 support bracket
The wall bracket must be fitted horizontally and the cable routed to the bottom right of the heater.
For optimal viewing of the pebble bed and the flame effects, it is advisable to install the fireplace at a height of 60
cm from the floor (measured from the bottom side of the glass panel).
Before mounting the fireplace on the wall, it is necessary to remove the front glass panel. Carefully place the
appliance on a flat and stable surface, away from any ornament or other object that may accidentally damage
the glass. Remove the screws found on the right and left side of the panel, and carefully remove the glass panel
by pulling upwards.
Note: it is advisable to use at least two people to carry out this operation, to avoid the accidental fall and
breakage of the panel.
It is now possible to proceed with wall mounting of the fireplace:
1. Select the wall location where you want to hang your electric fireplace heater. Draw a horizontal line using a
level and mark 4 drill holes for the anchor screws (Fig. A)
2. Drill 4 holes on the marked locations. Install the wall anchors into the holes and gently tap them into place with
a hammer until the flange of wall anchor is flush with the wall surface. (Fig. B)
3. Secure the anchor bracket to the wall anchors using the 4 screws provided (Fig. C)
4. Mount the fireplace on the wall using the slots of the metal bracket found at the back of the fireplace. Make
sure that the anchor bracket fixed on the wall is completely engaged into the metal bracket at the back of the
fireplace. (Fig. D)
5. Secure the support bracket to the bottom part of the fireplace using the 2 smallest screws provided. (Fig. E)
6. Mark the bottom holes position on the wall, and take the fireplace down. Drill the wall with applicable drill bit
and insert the wall anchors. Reinstall the fireplace and, using the 2 left screws, fasten the bottom support bracket
to firmly install the fireplace in place. (Fig. F)
7. Unpack the pebbles from the bag and place them along the light unit in the desired position.
