MANY COMMON PROBLEMS CAN BE SOLVED EASILY BY UTILIZING THE CHART
BELOW. FOR MORE SERIOUS OR PERSISTENT PROBLEMS, CONTACT A PORTER-
CABLE SERVICE CENTER OR CALL 1 888 848-5175.
To reduce the risk of serious personal injury, AlWAyS disconnect
air from tool and engage trigger lock, before all repairs.
SyMpTOM
Air leak near top of
tool or in trigger area
Tool does nothing or
operates sluggishly
Air leak near
bottom of tool
Tool jams frequently
Other
Height (inch/mm)
Width (inch/mm)
length (inch/mm)
Weight (lbs/kg)
Recommended Operating pressure 70-120 psi (4.8 to 8.3 bar)
Air Consumption per 100 cycles
loading capacity
TROUBleSHOOTInG GUIDe
pROBleMS
Loose screws.
Worn or damaged
o-rings or seals.
Inadequate air supply.
Inadequate lubrication.
Worn or damaged
o-rings or seals.
Loose screws.
Worn or damaged
o-rings or bumper.
Incorrect fasteners.
Damaged fasteners.
Bent collation wire.
Canister or nose screws loose Tighten screws.
Canister is dirty.
Driver tip is worn or damaged. Install Driver Maintenance Kit.
TOOl SpeCIFICATIOnS
15 - ENG
SOlUTIOnS
Tighten screws.
Install Overhaul Kit.
Verify adequate air supply.
Put 5 or 7 drops of
oil into air inlet.
Install Overhaul Kit.
Tighten screws.
Install Overhaul Kit.
Verify approved fasteners
of correct size and 15°
collation angle.
Replace with undamaged
fasteners.
Clean magazine.
Contact a PORTER-CABLE
Authorized Warranty
Service Center
Rn175B
10.63/ 270
4.33/ 110
10.24/ 260
4.78/ 2.17
4.13 CFM
120 nails
