G User Manual
Take your time and read the following instructions and information
completely. Please keep these instructions in a safe place for
future reference. If you sell the device, please pass these operating
instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your
attention to specific hazards and risks.
Note
This symbol is used to indicate additional information or important
notes.
2. Package Contents
• Power supply unit
• Power cable
• 9 Notebook adapter plugs
• These operating instructions
3. Safety Notes
• The product is intended for private, non-commercial use only.
• Protect the product from dirt, moisture and overheating, and only use
it in a dry environment.
• Do not drop the product and do not expose it to any major shocks.
• Do not operate the product outside the power limits given in the
specifications.
• Always pull directly on the plug when disconnecting the cable, never
on the cable itself.
• Make sure that cables do not pose a tripping hazard or block
emergency exits.
• Ensure that no electrical cables are crushed or damaged during
installation or adjusting.
• Keep this product, as all electrical products, out of the reach of
children!
• Do not modify the product in any way. Doing so voids the warranty.
• Keep the packaging material out of the reach of children due to the
risk of suffocation.
• Dispose of packaging material immediately according to locally
applicable regulations.
• Ensure that the power supply unit is sufficiently ventilated and that
heat can dissipate adequately.
Warning
• Only connect the product to a socket that has been approved for
the device. The socket must be installed close to the product and
easily accessible.
• Do not continue to operate the device if it becomes visibly
damaged.
2
All manuals and user guides at all-guides.com
4. Operation
• The adaptor plugs included with the power supply unit cover most
• Please select the correct adapter using the plug on the original power
• Test the selected adapter in the socket of the notebook while the
• Connect the correct adapter to the DC connection line of the power
• Do not use force under any circumstances. This may damage the
• First connect the power supply unit to the notebook. Then plug the
• When the power supply is active, the LED lights up to indicate that
• The terminal device can now be used and switched on or charged.
5. Care and Maintenance
• Only clean this product with a slightly damp, lint-free cloth and do not
• Make sure that water does not get into the product.
6. Technical Data
7. Disclaimer
Imtron GmbH accepts no liability for any losses or damages, resulting
from improper installation, assembly and usage of the product or
disregard of the operating instructions and/or the safety notes and
warnings.
Warning
• Ensure that your notebook requires a supply voltage of 18-20
volts; otherwise your device may be damaged.
• The specified supply voltage can be found on the original power
supply unit or in the user manual of your notebook. If you cannot
find the specification, do not connect your notebook and contact
the manufacturer.
• Ensure that the total power consumption of the notebook does
not exceed the power supply unit's rated output capacity of 65 W.
common notebooks from major manufacturers.
supply unit.
notebook is switched off and the power supply unit is NOT connected.
The plug should slide into the socket easily and fit securely without
too much play.
supply unit. This connection is protected against polarity reversal; i.e.,
the adapter fits easily onto the connection cable in one position only.
power socket of the notebook or the adapter.
electrical plug of the power supply cord into the electrical socket.
the power supply unit is ready for operation.
Warning
• Never attempt to forcibly connect the adapter plug in the wrong
position, as this can lead to the polarity being reversed.
• If the polarity is reversed, the notebook may be damaged.
use aggressive cleaning agents.
Input voltage
Output voltage
Max. Output Power
Maximum output current
100 – 240 V ~
50 / 60 Hz
19 V
90 W
4,73 A
