Scan here to view
product demo and install
videos or visit mnt.tv/102
Milestone AV Technologies
6436 City West Parkway
Eden Prairie, MN 55344 USA
Customer Service
888-333-1376 • 952-225-6011 • info@simplicityav.com
www.simplicityav.com
©2012 Milestone AV Technologies, a Duchossois Group Company.
All rights reserved. Simplicity is a Milestone brand.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
(6903-002002 <05>)
All manuals and user guides at all-guides.com
SMF2 Instruction Manual
Publicité
Manuels Connexes pour Simplicity SMF2
Sommaire des Matières pour Simplicity SMF2
- Page 1 888-333-1376 • 952-225-6011 • info@simplicityav.com www.simplicityav.com ©2012 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Simplicity is a Milestone brand. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners. (6903-002002 <05>)
- Page 2 All manuals and user guides at all-guides.com English - How to use this manual For best results, reference both the text and illustrations. Select one item or the other. This item is optional English Text Pages 3-13 Français - Utilisation de ce guide Pour obtenir de meilleurs résultats, reportez-vous à...
- Page 3 All manuals and user guides at all-guides.com English IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Specifi cations Weight capacity-DO NOT EXCEED: 27 kg (60 lb.) includes TV and any accessories Swivel: ±90° Tilt: +0°...
- Page 4 All manuals and user guides at all-guides.com Required Tools 13 mm 5.5 mm 10 mm (1/2 in.) (7/32 in.) (3/8 in.) Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
- Page 5 All manuals and user guides at all-guides.com Before You Begin Determine which interface to use Select a TV interface based on the particular hole pattern of your TV. DO NOT begin installation yet, only determine which interface to use. A. Use the smaller interface [04] for 75 - 200 mm hole patterns. B.
- Page 6 All manuals and user guides at all-guides.com 1 Select TV Hardware and Mount TV Interface 1-1 Select the hardware diameter and length Your TV type will help you determine which hardware confi guration to use. Match your type of TV to the suggested hardware confi guration on the next page.
- Page 7 All manuals and user guides at all-guides.com 1-2 Attach interface to a TV with an irregular back Attach shoulder washers [16] and spacers to the brackets [02] or [04]. Push the shoulder washer [16] through the appropriate openings of the brackets [02] or [04]. [02] Snap shoulder washer [16] into the spacer [19] or [20] you selected in step 1-1.
- Page 8 All manuals and user guides at all-guides.com 1-3 Assemble large interface For the large interface ONLY. If using the smaller interface [04], proceed to step 2. Insert tube assemblies [05] through brackets [01, 02]. If necessary, loosen the carriages (C) using the 3/16 allen key [21]. Be sure that the center bracket [01] is centered.
- Page 9 All manuals and user guides at all-guides.com 2 Mount the Wall Plate Wood stud 13 mm 5.5 mm (1/2 in.) (7/32 in.) 2-1 Locate studs Verify the center of the stud using an awl, a thin nail, or an edge to edge stud fi nder.
- Page 10 All manuals and user guides at all-guides.com 2 Mount the Wall Plate Solid concrete or concrete block 13 mm 10 mm (3/8 in.) (1/2 in.) 2-1 Mark the wall For assistance in determining wall plate location, see Mount Wizard at simplicityav.com Level the wall plate [03] and mark the hole locations.
- Page 11 All manuals and user guides at all-guides.com 3 Attach your TV to the Arm 3-1 Position arm Position arm [03] so the elbow is pressed against the wall. Tighten the tension adjustment [T] to prevent the arms from moving while installing the TV bracket. [03] 3-2 Attach TV HEAVY! You will need assistance with this step.
- Page 12 All manuals and user guides at all-guides.com 4 Set Adjustments 4-1 Adjust level [22] 4-2 Adjust up/down tilt tension [01] [03] 4-3 Adjust arm extend / retract tension [22] 6903-002002 <05>...
- Page 13 All manuals and user guides at all-guides.com 5 Manage Cables [23] [23] 6903-002002 <05>...
- Page 14 All manuals and user guides at all-guides.com Français CONSIGNES DE SÉCURITÉ IMPORTANTES – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ATTENTIVEMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Caractéristiques techniques Capacité de charge – NE PAS DÉPASSER : 27 kg (60 lb) incluant le téléviseur et tous les accessoires. Pivotement : ±90°...
- Page 15 All manuals and user guides at all-guides.com 2 Installation de la plaque murale - LISEZ D'ABORD CECI Voir les illustrations de la page 8 IMPORTANT : Le support pivotera de 95,4 mm (3.75 po) dans chaque direction à partir du centre lorsqu’il est en position « Repos ». Veuillez considérer cet aspect lorsque vous choisirez l’emplacement de votre support mural.
- Page 16 All manuals and user guides at all-guides.com Español INSTRUCCIONES DE SEGURIDAD IMPORTANTES – CONSERVE ESTAS INSTRUCCIONES – LEA TODO EL MANUAL ANTES DEL USO Especifi caciones Peso máximo admitido-NO LO EXCEDA: 27 kg (60 lb), que incluye el televisor y los accesorios. Rotación: ±90°...
- Page 17 All manuals and user guides at all-guides.com 2 Monte de la placa mural - LEA ESTO PRIMERO Consulte los gráfi cos de la página 8 IMPORTANTE: El montaje deberá girar 95,4mm (3.75 pulgadas) en cualquier dirección desde el centro cuando está en la posición inicial. Considere esto a la hora de seleccionar la ubicación de su placa mural.
- Page 18 All manuals and user guides at all-guides.com English Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product.
