QUICK PROGRAMMING STEPS
1 Remove mains supply if present, then restore mains voltage.
2 The "Service Light" of the control unit starts to flash.
3 Press the hidden key of the transmitter to be stored, the "Service Light" stays on.
4 Press the desired key to associate with the receiver within 5s, the "Service Light" flashes a few times to confirm receipt, then flashes again.
5 Repeat steps 3 and 4 for the following transmitters to be stored, up to a maximum of 64 transmitters.
6 To move to the next autoset phase, press and hold down the key of a transmitter already stored until the AUTOSET phase starts
7 The LD1/2/3 LEDs light up cyclically and a number of movements are performed automatically, calculating optimal operating parameters. If the
autoset operation is successful, the panel stops in the open position and the LED lights remain steady for 5s to confirm AUTOSET correctly carried
out.
The maximum time for programming the first transmitter is 60 seconds.
If necessary proceed with manual configuration of Trimmers and DIP-SWITCHES according to the type of installation.
To skip the quick programming phase and proceed with manual programming, press the PU1 PU2 keys for 1s at any time.
ARC TRANSMITTERS
IMPORTANT, PLEASE READ CAREFULLY:
The radio receiver in this product is compatible only with ARC (Advanced Rolling Code) transmitters which, thanks to 128 bit coding, guarantee
superior anti-copying security.
TRIMMER FUNCTION
TCA Trimmer
Allows to adjust automatic closing time. Adjustment may vary from a minimum of 3s to a maximum of 180s.
With the TCA trimmer turned completely clockwise the TCA is disabled.
With TCA active and the panel open, the LD1 LED starts flashing quickly to indicate the counting of the TCA time in progress.
AMP Trimmer
Adjustment of the sensitivity of the amperometric sensor for obstacle detection during opening and closing.
Rotate the trimmer clockwise (+) to increase the torque, turn counter-clockwise (-) to decrease the torque.
In the case of obstacle detection:
- Stops movement during opening.
- Stops and reopens the panel for about 3s during closing .
CAUTION:
The AMP trimmer increases or decreases the value that the control unit has set in the various points of the run during AUTOSET phase.
It should therefore be set only after a complete AUTOSET procedure and in compliance with the regulations in force.
DIP-SWITCH FUNCTION (S1)
DIP 1
DIP 1 enables to:
- Enable/disable pre-flashing
- Enable/disable SASO function (panel stop before mechanical opening stop).
- Enable/disable remote transmitter acquisition
The procedure involves switching DIP1 to ON, carrying out the operations described, then switching it back to OFF to confirm programming.
PRE-FLASHING enabling/disabling
Switching DIP1 to On with the PU2 key will enable or disable pre-flashing.
The LD1 LED indicates the status of the function:
LED LD1 on = Pre-flashing enabled. The flashing light activates 3s before the motor starts.
LED LD1 off = Pre-flashing disabled. (default)
CAUTION: Switch DIP 1 to OFF at the end of programming.
Enable/disable SASO function
Switching DIP1 to On with the PU1 key enables or disables the SASO function.
The SASO function involves stopping the panel before the mechanical opening stop (about 1 cm), thus obtaining a gradual stop without vibrations.
The LD2 LED indicates the status of the function:
LED LD2 on = SASO enabled (default)
LED LD2 off = SASO disabled
CAUTION: Switch DIP 1 to OFF at the end of programming.
Enabling/disabling of remote transmitter acquisition
Switching DIP1 to On by simultaneously pressing PU1 + PU2 enables or disables remote acquisition, as described in the paragraph "Remote acquisition
of transmitters".
Please note: Reception of duplicate "AK" series transmitters is simultaneously enabled or disabled.
The LD3 LED indicates the status of the function:
LD3 LED on = Remote acquisition enabled (default)
LD3 LED off = Remote acquisition disabled
CAUTION: Switch DIP 1 to OFF at the end of programming.
DIP 2
Set the OPENING and CLOSING movement speed.
After switching DIP2 to ON, select the CLOSING speed indicated by LED LD3 using the PU1 key.
LD3 1 flash 50% of maximum speed (Default)
LD3 2 flashes 75% of maximum speed
LD3 steady light maximum speed
After switching DIP2 to ON, select the OPENING speed indicated by LED LD1.
LD1 1 flash 50% of maximum speed
LD1 2 flashes 75% of maximum speed (Default)
LD1 steady light
maximum speed
Slowing down speed is not changed.
CAUTION: At the end of programming switch DIP 2 back to OFF, the service light starts to flash, give a S.S. command, an opening (or closing) movement
is commanded during which operation parameters are updated then, at the end of the movement, the service light switches off.
DIP 3
Enabling and disabling sharing function.
On: Sharing function enabled.
The S.S. Or transmitter impulse has no effect during the opening phase and during TCA pause.
Off: Sharing function disabled (default).
