4) ASSEMBLING ONTO BALANCING DOORS
Overhead door with balanceweights (fig.15): these doors need the special arm art. AU.C25.
In order to assemble it make sure that:
• the arm is fixed to the top edge of the door.
• the arm is levelled.
AU.C25 is an accessory which allows the installation of the automatic system of counterweight balancing doors.
To install the AU.C25 arm proceed as follows (Fig. 15):
- Fit the arm on the upper edge of the door, in a PERFECTLY centred position (ref.A)
- Check that the arm is PERFECTLY PERPENDICULAR, fix the arm in the lower part of the door (ref. B).
- If fitted, remove the bent arm from the dragging slider (ref. C.)
- Fix the straight, adjustable arm supplied with AU.C25 at its place (ref.D)
- By using the two screws and 4 spacers supplied, fit the straight arm to the AU.C25 arm (ref.E)
- The holes on the right arm allow the adjustment of the door position with respect to the arm (ref.F)
- IMPORTANT: with completely closed door, the dimension X must be around 2/3 cm.
- It is advisable to remove the closing mechanical lock (ref. G).

5) ELECTRIC CONNECTIONS

The cables necessary for the installation can vary according to the accessories installed.
All of the accessories indicated in the layout in figure 12 are optional.
No connection cable is supplied for the accessories.
List of cables
Connection
A Mains power supply to the control unit
B Photocell transmitter connection
C Photocell receiver connection
D Key selector connection or digital keyboard for external command
E Flashing signal light connection
F Connection of the aerial built-in the flashing light
Notes
The mains power supply connection can be made via the supplied plug (Fig.13), connected to an electrical socket already prepared (fig. 13) or
[1] in the case of the removal of the plug.
An omnipolar switch/section switch with remote contact opening equal to, or higher than 3mm must be provided on the power supply mains.
There is an aerial pre-installed in the control unit (cable), which in most cases makes this connection superfluous. The capacity of the receiver
[2]
can be improved by connecting the aerial in the flashing light or an outdoor antenna 433,92 MHz
6) CP.J3-SW CONTROL UNIT

ELECTRICAL CONNECTIONS

The follows table shows the electrical connections in Fig. 17:
Terminals Function
L/N/GND Power supply
MOT/+ENC- Motor/Encoder
ANT/SHIELD Antenna
COM General
S.S. Step-by-Step
STOP STOP
PHOT Photocell
BLINK Flashing
+ 24V - 24 Vac/dc
J6 X.BE
M5 LED
M6 Battery charger

QUICK PROGRAMMING

The procedure described below enables to programme one or more transmitters and perform control panel AUTOSET.
PLEASE NOTE: Preliminary conditions for quick programming:
- Receiver with less than 64 stored transmitters
- Autoset never performed.
If mistakes are made during the quick programming phase, disconnect the mains power supply and restart the initial procedure.
16
Description
230Vac 50/60Hz input (L-Phase / N-Neutral / GND)
Quick connector for the connection of motors provided with Encoder
Built-in radio receiver antenna connection
ANT: Signal/SHIELD: Display
Common for all control inputs.
Step-by-step key input (N.O. contact). The control unit executes a command at each S.S. impulse
according to the sequence: OPEN>STOP>CLOSE>STOP>OPEN...
STOP button input (N.C. contact)
Photocell input active only in the closing phase (N.C. contact).
24Vdc flashing connection 15W max.
Power supply output accessories 24Vdc/500mA max.
Quick connector for KNX interface card (item X.BE - See paragraph KNX)
Quick connector for optional additional LED light connection (item__)
Quick connector for optional battery charger card connection (item CB.SW)
Type Maximum length and notes
3x1,5mm [1]
2
2x0,5mm 2 20m
4x0,5mm 20m
2
4x0,5mm 20m
2
2x1,0mm 10m
2
RG 58 [2]
