Corolla (LHD)
Toyota Parking Aid 800
Installation instructions
Model year:
Vehicle code:
Part number:
Weight:
Installation time:
Manual reference number: AIM 000 783-1
2006
**E15*L-*E***W
PZ464-00425-B0
PZ464-00421-**
PZ464-00420-55
Main Kit
1,9 kg
5.1 hour
Sensor Kit
0,3 kg

Publicité

loading

Manuels Connexes pour Toyota Parking Aid 800

Sommaire des Matières pour Toyota Parking Aid 800

  • Page 1 Corolla (LHD) Toyota Parking Aid 800 Installation instructions Model year: 2006 Vehicle code: **E15*L-*E***W Part number: PZ464-00425-B0 PZ464-00421-** PZ464-00420-55 Weight: Main Kit 1,9 kg Sensor Kit 0,3 kg Installation time: 5.1 hour Manual reference number: AIM 000 783-1...
  • Page 2 Revision Record Rev. No. Date Page Picture Update Deleted Steps 12-07-10 Manual Ref. no. AIM 000 783-1 2 of 49...
  • Page 3 I Expert Fitment Required. I Montage durch Fachwerkstatt erforderlich. I Disconnect the battery earth cable. I Massekabel von Batterie abklemmen. I To avoid damage to the wiring harness, ensure I Zur Vermeidung von Beschädigungen an der contact with sharp edges is prevented. Kabelisolation ist Berührung mit scharfen Kanten zu vermeiden.
  • Page 4 Nødvendig med montering fra fagvegverksted. Verkstadsmontage erfordras. Klem jordkabelen av batteriet. Lossa stomkabeln från batteriet. For å unngå skader på kabelisoleringen må För att förhindra skador på ledningarnas isolation berøring av skarpe kanter unngås. skall beröring med vassa kanter undvikas. Montera detaljerna enligt figurerna Monter alle deler i henhold til illustrasjonene.
  • Page 5 Blue Blau Azul Bleu Azul Blauw Blå Black Schwarz Negro Noir Nero Preto Zwart Sort Brown Braun Marrón Marron Marrone Castanho Bruin Brun Green Grün Verde Vert Verde Verde Groen Grøn Grey Grau Gris Gris Grigio Cinzento Grijs Grå Natural colour Naturfarben Color natural Nature Colori naturali...
  • Page 6 PZ464-00420-55 PZ464-00421-** Manual Ref. no. AIM 000 783-1 6 of 49...
  • Page 7 Ø 2 mm Ø 15 mm Ø 20 mm CLEAN Würth Art. No. Würth Art. No. 0557 900 445 0558130 1-16 49-74 17-48 Only PZ464-00421-AB 40 of 49 41 of 49 Manual Ref. no. AIM 000 783-1 7 of 49...
  • Page 8 Manual Ref. no. AIM 000 783-1 8 of 49...
  • Page 9 Manual Ref. no. AIM 000 783-1 9 of 49...
  • Page 10 Manual Ref. no. AIM 000 783-1 10 of 49...
  • Page 11 CLEANER Manual Ref. no. AIM 000 783-1 11 of 49...
  • Page 12 30 mm 30 mm 40 mm 40 mm 30 mm Manual Ref. no. AIM 000 783-1 12 of 49...
  • Page 13 "INSIDE BUMPER" 42 of 49 45 of 49 400 mm 620 mm 400 mm Manual Ref. no. AIM 000 783-1 13 of 49...
  • Page 14 Manual Ref. no. AIM 000 783-1 14 of 49...
  • Page 15 10mm Manual Ref. no. AIM 000 783-1 15 of 49...
  • Page 16 Manual Ref. no. AIM 000 783-1 16 of 49...
  • Page 17 46 of 49 49 of 49 "INSIDE BUMPER" 400 mm 400 mm 400 mm Manual Ref. no. AIM 000 783-1 17 of 49...
  • Page 18 Manual Ref. no. AIM 000 783-1 18 of 49...
  • Page 19 Option A Option C Option B Option A CLEANER Manual Ref. no. AIM 000 783-1 19 of 49...
  • Page 20 Option B CLEANER Option C CLEANER Manual Ref. no. AIM 000 783-1 20 of 49...
  • Page 21 CLEANER Manual Ref. no. AIM 000 783-1 21 of 49...
  • Page 22 Option A Option B Option C CLEANER Manual Ref. no. AIM 000 783-1 22 of 49...
  • Page 23 KEEP CLEAR CLEANER Manual Ref. no. AIM 000 783-1 23 of 49...
  • Page 24 34-40 Manual Ref. no. AIM 000 783-1 24 of 49...
  • Page 25 CHECK Ref: Toyota Wire Harness Repair Pub No. RM 1022E Page B 30 - 31 Paragraph 6 CLEAN 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) Manual Ref. no. AIM 000 783-1...
  • Page 26 CLEANER Manual Ref. no. AIM 000 783-1 26 of 49...
  • Page 27 CLEANER Manual Ref. no. AIM 000 783-1 27 of 49...
  • Page 28 Manual Ref. no. AIM 000 783-1 28 of 49...
  • Page 29 Manual Ref. no. AIM 000 783-1 29 of 49...
  • Page 30 Optional 15 mm 20 mm Manual Ref. no. AIM 000 783-1 30 of 49...
  • Page 31 Manual Ref. no. AIM 000 783-1 31 of 49...
  • Page 32 Option A Option B Option A1 Option A1 15 mm 15 mm Click Manual Ref. no. AIM 000 783-1 32 of 49...
  • Page 33 Click Click Click Manual Ref. no. AIM 000 783-1 33 of 49...
  • Page 34 "WIRE VIEW" (IG+) (SPD or S+) 55-61 62-68 +15V 120 140 (IG+) (SPD or S+) Manual Ref. no. AIM 000 783-1 34 of 49...
  • Page 35 CHECK Ref: Toyota Wire Harness Repair Pub No. RM 1022E Page B 30 - 31 Paragraph 6 CLEAN 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) Manual Ref. no. AIM 000 783-1...
  • Page 36 CHECK Ref: Toyota Wire Harness Repair Pub No. RM 1022E Page B 30 - 31 Paragraph 6 CLEAN 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) 10 mm (0.39 in) Manual Ref. no. AIM 000 783-1...
  • Page 37 CLEANER CLEANER Manual Ref. no. AIM 000 783-1 37 of 49...
  • Page 38 Manual Ref. no. AIM 000 783-1 38 of 49...
  • Page 39 TOYOTA TPA800 SET-UP Corolla Rear Bumper Selection Front Bumper Selection Rear Power Selection AIM 000 388 Front Power Selection Manual Ref. no. AIM 000 783-1 39 of 49...
  • Page 40 Manual Ref. no. AIM 000 783-1 40 of 49...
  • Page 41 Manual Ref. no. AIM 000 783-1 41 of 49...
  • Page 42 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 42 of 49...
  • Page 43 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 43 of 49...
  • Page 44 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 44 of 49...
  • Page 45 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 45 of 49...
  • Page 46 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 90 100 Manual Ref. no. AIM 000 783-1 46 of 49...
  • Page 47 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 90 100 Manual Ref. no. AIM 000 783-1 47 of 49...
  • Page 48 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 48 of 49...
  • Page 49 90 100 CHECK SIZE Print 100% Check with Rulers before use. Corolla **E15*L-*E***W 2006 Manual Ref. no. AIM 000 783-1 49 of 49...
