Kimpex CLICK N GO 2 Instructions D'assemblage page 6

"CLICK N GO 2" MOUNTING PLATE
Polaris Touring 500 HO
3) Pass the two (2) M8-1.25 x 60 mm carriage bolts
Fig. 3
4) Fix the pre-assembly of the universal mounting plate
(6) M8-1.25 nuts . Make sure the plate is well centered (left and right) under the vehicle.
03
Fig. 4
5) Tighten all nuts.
