WARNING
Read the instructions in this manual carefully. Tecomec is not responsible for problems
generated by negligence of users, by no respect of the instructions written on this
manual and for damages caused by careless usage.
PRECAUTIONS
Comply with the specified power supply voltage (12 ±10%Vdc).
Never expose the equipment to jets of water.
Never use solvents or petroleum spirit for cleaning the outside parts of the container.
In case of electric arc welding, make sure that the power supply to the switch box is disconnected; if
necessary disconnect the tractor battery wires.
Use only original Tecomec parts or accessories.

POSSIbLE APPLICATIONS

This equipment is projected for installations on agricoltural spraying machines.
NOTA:all instructions and technical features given here below refer to products that Tecomec is
distributing at the time when this manual has been printed. To follow the standard product evelopment,
Tecomec reserves the right to modify and update this manual at any time and without notice.
TECHNICAL FEATURES AND PERFORMANCE
Description
Power supply voltage
Oparating temperature
INSTALLATION
Switch box
Fix the box close to the driving seat, in a clearly visible but protected position, using the bracket pro-
vided. provided. The switch box must be easy to reach by the operator and has not to restrict the view
from the driving seat.
Fig.3-5 Connect the extention cable Ci (if used) with the control panel (using the Pi socket) and the
end cable Cf.
Fix the wiring so that it cannot come into contact with moving parts.
To connect "RI" electric control panels always use the extension cable.
Connecting the valves
Fit the gaskets on the connectors which connect the valves to the end cable Cf.
Fig.3
Fix all connectors to the relevant valves, following instructions given on picture 3, and as ap-
propriate to the type of switch box:
gulator valve
P
Re
G
Main control valve
1
Electric section valve 1
2
Electric section valve 2
WARNING: The number of connectors to be connected to the section valves depends on the
type of switch box and the cable combined with it.
4
Data
12 Vdc ±10%
- 5° +70 °C
3
Electric section valve 3
4
Electric section valve 4
5
Electric section valve 5
Use & Instruction Manual
ENG
