Installation Preparation - VIBIA Set Instructions De Montage

Step 3/5

Installation Preparation

3.1
3.2
6/13
Points to mark
Ref. Puntos a marcar
Punkte zum markieren
7750 Ref. 7750 (1 ut.) + T1 (2 uts.)
7751 Ref. 7751 (2 uts.) + T1 (2 uts.)
Ref. 7752 (3 uts.) + T1 (2 uts.)
7752
7753 Ref. 7753 (4 uts.) + T1 (2 uts.)
7760 Ref. 7760 (1 ut.) + T2 (2 uts.)
7761 Ref. 7761 (2 uts.) + T2 (2 uts.)
7762 Ref. 7762 (3 uts.) + T2 (2 uts.)
7763 Ref. 7763 (4 uts.) + T2 (2 uts.)
7764 Ref. 7764 (5 uts.) + T2 (2 uts.)
-Line parallel to floor
-Línea paralela al suelo
-Parallel zum Bodem verlaufende Linie
