7.
INSTALL SIDE BRACKET SCREWS
AND COVERS
a. For each installed bracket, pre-drill in the
center of each elongated hole with a
bit (Fig. 17).
NOTE: In some cases you will be drilling
though aluminum as well
as the vinyl railing.
b. Install #10 x 1" screws in all pre-drilled holes
(10' only) (Fig. 18).
c. Match letter on inside of bracket cover to the
letter on bracket, and snap cover in place.
Repeat for all brackets (Fig. 19).
6
Between Posts
⁄ " drill
1
8
Over Posts
Fig. 18
Fig. 15
Fig. 16
Fig. 17
Fig. 19
