PREPARE THE PEDESTAL
2
A
Pull the
drawer out
as far as it
will go.
B
Remove screws
from drawer
slides. Slide
drawer out of
the base and
set aside.
FOR DRYERS ONLY:
C
Locate the 4 support pads from the parts
package. Each pad has 2 protrusions that fit
into the holes on top of the pedestal. Press
the rubber pads into each set of corner holes
on the top of the pedestal as shown.
NOTE: The support pads should be installed on
the dryer only. DO NOT INSTALL THESE PADS ON
THE WASHER PEDESTAL.
Installation Instructions
2
INSTALL THE PEDESTAL
3
TO THE WASHER OR DRYER
Place the pedestal against the bottom
A
of the unit. Check to be sure the drawer front
is at the front of the unit.
B
Align the holes in the pedestal with the
holes in the bottom of the unit. Use a Phillips
screwdriver to install the 4 screws through the
pedestal and into the unit—do not tighten.
Slide the pedestal toward the unit, until it is
C
aligned front to back. Use an 8 mm socket
wrench to securely tighten the screws.
