Operating Mode 5
When using with the M300 RTK, the remote controller must join the broadcast network of the D-RTK 2
Mobile Station.
1. Power on the D-RTK 2 Mobile Station, wait until system initialization is completed, and enter
Operating Mode 5.
2. Power on the remote controller. Go to RTK Settings in the DJI Pilot app, and set the RTK signal
source to D-RTK 2 Mobile Station.
3. Tap on the right of the D-RTK 2 Mobile Station status display and a search will start automatically.
Select the desired RTK base station in the search results and wait for a successful connection.
Link Indicator Descriptions
When the linking process starts, the indicator blinks red and green alternately.
When the linking process is finished, the indicator blinking patterns are as shown below.
Operating Mode 1/3/4
Solid Green
Quick Green Blink
Slow Green Blink
Solid Red
Operating Mode 2
Solid Green
Solid Red
Operating Mode 5
Solid Green
Activation
Make sure to activate the D-RTK 2 Mobile Station before first-time use. Activation can be done in the
app or in the DJI ASSISTANT
Using with Agras or Phantom 4 RTK Aircraft
1. Power on the D-RTK 2 Mobile Station.
2. Power on the remote controller and make sure that the app is launched.
3. In the app, go to RTK Settings to enable the aircraft RTK function. Select the RTK signal source to
D-RTK 2 Mobile Station. When connecting for the first-time, a prompt for activation will appear. Follow
the on-screen steps for activation.
Using with M300 RTK or M210 RTK V2 Aircraft
Power on the mobile station, and make sure that it is linked to the aircraft or remote controller. Launch
the DJI Pilot app and follow the on-screen steps for activation.
8
Status
OcuSync signal quality >70%
OcuSync signal quality 35%-70%
OcuSync signal quality ≤ 35%
OcuSync signal quality = 0
Status
Network connected
Network disconnected
Status
Working normally
TM 2 software. The following descriptions use the app for example.
