EN
English
1. Technical Data (See figures 1.)
Blows per minute Bore & stroke
Model
1
[min-1]
RC5185 3 000
RC5195 2 100
:Vibrations, k Uncertainty , L
a
h
Declaration of noise and vibration statement (ISO 15744 and ISO28927-6)
All values are current as of the date of this publication. For the latest information please visit www.cp.com.
These declared values were obtained by laboratory type testing in accordance with the stated standards and are suitable for comparison with the declared
values of other tools tested in accordance with the same standards. These declared values are not adequate for use in risk assessments and values measured
in individual work places may be higher. The actual exposure values and risk of harm experienced by an individual user are unique and depend upon the way
the user works, the workpiece and the workstation design, as well upon the exposure time and the physical condition of the user. We, CHICAGO PNEUMATIC
TOOLS , cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk assess-
ment in a work place situation over which we have no control. This tool may cause hand-arm vibration syndrome if its use is not adequately managed. An EU
guide to managing hand-arm vibration can be found at www. pneurop.eu/uploads/documents/pdf/PN3-02-NV_Declaration_info_sheet_0111.pdf We recommend
a programme of health surveillance to detect early symptoms which may relate to noise or vibration exposure, so that management procedures can be modified
to help prevent future impairment.
2. Machine type(s)
• This product is designed for installing and removing threaded fasteners in wood, metal and plastic.This product is designed for drilling or reaming holes.No
other use permitted. For professional use only.
• Please read the instructions carefully before starting the machine.

3. Mounting instruction

• See figures
4. Lubrification motor
Use an air line lubricator with SAE #10 oil, adjusted to two drops per minute. If an air line lubricator cannot be used, add air motor oil to the inlet once a day.
Recommended lubricant CP Oil PROTECTO-LUBE:
- 4 oz (0.12l) P/N: CA149661
- 20.8 oz (0.591l) P/N: CA000046
- 1gal (3.8l) P/N: P089507
5. Maintenance instruction
• Follow local country environmental regulations for safe handling and disposal of all components
• Maintenance and repair work must be carried out by qualified personnel using only original spare parts. Contact the manufacturer or your nearest authorised
dealer for advice on technical service or if you require spare parts.
• Always ensure that the machine is disconnected from energy source to avoid accidental operation.
• High wear parts are underlined in the parts list.
• To keep downtime to a minimum, the following service kits are recommended:
Tune-up kit: see part list
6. Disposal
• The disposal of this equipment must follow the legislation of the respective country.
• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.
• Repair only by technical maintenance staff.

7. Declaration of conformity

We : Rodcraft Customer CenterLangemarckstr.35 bis 45141 Essen- Germany
Declare that the product(s): RC5185 & RC5195
Machine type(s): Air hammer
Origin of the product: Taiwan
is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to "Machinery" 2006/42/EC (17/05/2006)
applicable harmonised standard(s) : EN ISO 11148-4 :2012
Name and position of issuer : Nicolas Lebreton ( R&D Manager)
Place & Date: Saint-Herblain, 20/07/2014
Technical file available from EU headquarter. Nicolas Lebreton R&D manager LLC CP Technocenter 38, rue Bobby Sands - BP10273 44800 Saint Herblain - France
Original Instructions are in English. Other languages are a translation of the original instructions.
Copyright 2014, Chicago Pneumatic Tool Co. LLC
All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability..
Air consumption
@ load
2 3
[mm] [l/s]
19 x 70 6.2
19 x 95 6.2
Sound pressure dB(A), K = K
pA pA
Serial Number: From 001 to 999
Weight Dimension Hose Ø
4 5
[kg] [mm] [mm]
1.7 179x57x163 9.5
2 223x57x163 9.5
= 3 dB Uncertainty.
WA
RC5185 & RC5195
Sound
Air Inlet pressure
L
pA
6 7 8
[inch]
[dB(A)]
1/4' 102
1/4' 102
Air hammer
Vibrations
Sound-
power
a k
L
h
wA
9 10
[dB(A)] [m/s²] [m/s²]
113 8.2 1.2
113 11.9 1.5
