Nice HSSOC Instructions Pour L'installation

EN - Installation instructions:
abridged manual; for further information see
instruction manual for the control unit
IT - Istruzioni per l'installazione:
manuale ridotto, per ulteriori informazioni vedere
manuale istruzioni della centrale
FR - Instructions pour l'installation :
guide réduit, pour plus de détails, voir le guide
d'instructions de la logique de commande
ES - Instrucciones para la instalación:
manual sintético, para más informaciones véase el
manual de instrucciones de la central
DE - Anleitungen für die Installation:
Eingeschränktes Handbuch – für weitere Informationen
siehe Gebrauchsanleitung der Steuerung
PL -
skrócona instrukcja obsługi; aby uzyskać więcej
informacji przeczytaj instrukcję obsługi centrali
NL - instructies voor de installatie:
beknopte handleiding, zie voor meer informatie de
instructiehandleiding van de besturingseenheid
ENGLISH
1 – SPECIAL WARNINGS
Install the product in a location difficult to reach, to avoid inadvertent dam-
age.
2 – INSTALLATION AND ELECTRICAL CONNECTION
CAUTION! – All electrical connections must be made with the unit disconnect-
ed from the mains power supply.
01. Open the box (fig. 1);
02. Prepare the hole for the routing of cables: detach the plastic part as shown in fig.
2. Caution! – Do not dispose of the plastic element removed; it is used subse-
quently to activate the tamper-proof system if required (point 03);
03. Before mounting HSSOC on the wall, if required, the tamper-proof system can
be activated; this means that if the box is opened, detached from the wall and/or
broken into, the siren transmits the event to the control unit for activation of an
acoustic and visual signal. To activate this function, proceed as shown in fig. 3.
04. Route the electric cables through the hole and fix HSSOC to the wall by means
of the screws and plugs supplied (fig. 4);
05. Before making the electrical cable connections, the required operating mode
must be selected (fig. 5):
a) with alarm block: with the alarm active, when the set number of alarms is
exceeded, the alarm signal is shut off;
b) without alarm block: with the alarm active, the alarm signal is continuous;
06. Make the electrical connections on HSSOC:
- buffer battery (not supplied): see fig. 6, the lamp flashes (if the lamp is per-
manently lit, this means that the battery is not inserted correctly);
- power supply from control unit: see fig. 7;
To connect the control unit power supply, refer to the relative instruction manual.
HSSOC confirms correct connection by emitting 2 beeps and the lamp stops
flashing;
07. Close the box (fig. 8); HSSOC emits a beep to confirm correct closure; if this
does not occur, check closure.
HSSOC performs a self-programming function when activated/deactivated for the
first time on the control unit (see control unit instruction manual).
3 – BUFFER BATTERY REPLACEMENT
01. Set the control unit to "TEST" mode (see control unit instruction manual);
02. Open the HSSOC box (fig. 1);
All manuals and user guides at all-guides.com
Instrukcje montażu:
Nice HSSOC
Home security outdoor siren
0682
03. Disconnect the buffer battery, replace with a new battery of the same type and
then reconnect, observing the specified polarity (fig. 5): the control unit emits a
beep to confirm successful learning;
04. Close the box (fig. 9); HSSOC emits a beep to confirm correct closure; if this
does not occur, check closure.
4 - TECHNICAL SPECIFICATIONS
WARNINGS: • All technical specifications stated in this section refer to an ambient
temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to apply modifications
to products at any time when deemed necessary, maintaining the same intended
use and functionality.
I Type: outdoor siren with cable connection to control unit and built-in flashing light
I Power supply: 12 Vdc + 2.2 Ah buffer battery with estimated autonomy of 4
days
I Acoustic alarm: 116 dB at 1 m
I Visual alarm: lamp 5 W, 12 V flashing
I Autonomy: 4 days with buffer battery
I Absorbed current: on standby maximum 5 mA - 2 A in alarm status
I Protections: internal battery anti-inversion device
I Timers: max. 3 minutes for each flashing light – count control of 3 or 5 alarms
I Radio reception/transmission: digital bidirectional communication, in dual band
frequency (433 and 868 MHz) with quartz control; devices pre-encoded in the
factory and managed in self-learning mode
I Radio range: 100 m in open field free of disturbance or approx. 20 m inside
buildings.
I Insulation: class II
I Operating temperature: from -20 °C to +55 °C
I Use in class III environments
I Assembly: vertical, wall-mounted.
I Dimensions (mm): 207 x 203 x 73 mm
I Weight: 1.560 kg
