RGCOMBO2 Roll Groover
Description and Specifications
Description
The Reed RGCOMBO2 Roll Groover is designed to form
standard rolled grooves in steel, stainless steel and
aluminum pipe, from 1 1/4" to 6", in both Schedule 10 and
Schedule 40 pipe. The groove is formed by the groove roll
which is fed into the pipe wall. The pipe is supported on
the inside by a drive roll, which is relieved to permit pipe
wall deformation. The formed grooves comply with the
specifications required for mechanical coupling systems.
The only adjustment required is for the depth of the groove.
Designed for portability, the RGCOMBO2 Roll Groover is an
economical solution to the job-site grooving requirements
in mechanical piping system installations. Although the
RGCOMBO2 design has many improvements over similar
competitors' models, it is not intended for production
work in the fab shop.
The RGCOMBO2 Roll Groover is designed for use with
the Reed #05301 5301PD Power Drive.
Specifications
Capacity....................... 1 1/4" - 6" (32 - 152 mm) Schedule 10
1 1/4" - 6" (32 - 152 mm) Schedule 40
Depth Adjustment....................................Adjusting Screw and
Actuation........................Feed Screw (included ratchet wrench)
REED 5301 Power Drive Mounting....RIDGID
Weight............................................................................31.4 lbs.
Standard Equipment
Groove Roll.................................................................1 1/4" - 6"
Drive Roll (Drive Shaft)..............................................1 1/4" - 6"
Feed Handle.......................................Included Ratchet Wrench
Support Means......................................Included Support Rods
Recommended Accessories
• Reed JHV Pipe Jack with JTA Ball Transfer Head, or JH2R
Roller Head Jack
• Reed 2-71 Pipe Reamer
• Reed 5301PD Power Drive
RIDGID® is a registered trademark of RIDGID, Inc. and is not associated with Reed Manufacturing Co.
2
Included Depth Gauges
300 Power Drive
(38 RPM model only)
Important - Before Operating
Before operating the RGCOMBO2 Roll Groover,
read and follow all safety information and instructions in the
operator's manual.
Safety Information
WARNING!
Serious injury can occur if all safety information and
operating instructions are not followed. These injuries
could include:
Loss of fingers, hands, arms or other body parts if clothing
or gloves get caught in moving parts;
Electrical shock or burns from contact with wires, motor or
other power drive parts;
Impact injuries, including broken bones if machine tips over
or workpiece falls.
Eye injuries, including being blinded by thrown workpiece
or workpiece chips.
General Safety
Read and follow the safety information and instructions
in the operator's manual.
Know the location and functions of all controls before
using the machine.
Footswitch Safety
The footswitch of the power drive is for your safety. It
lets you shut off the motor by removing your foot. If
clothing should become caught
in the machine, it could continue
to wind up, pulling you into the
machine. Because the machine has
high torque, the clothing itself can
bind around your arm or other body
parts with enough force to crush or
break bones.
Operator's Manual
0217-59200
