4. REVERSING THE DOORS (continued)
REINSTALLING THE REFRIGERATOR DOOR
1. Lower the refrigerator door onto the bottom hinge pin.
2. While holding the door securely, use the new left-hand middle hinge from the accessory kit insert hinge pin into socket
in door. Attach the center hinge with two screws with a 5/16 "socket wrench.
REHAND THE FREEZER DOOR
1. Lower the freezer door onto the center hinge pin.
2. Place the left top hinge lined up with the door socket
Hold the door on the handle side and make sure the door is straight and the gap between the 2 doors is even
accessories)
across the front. While holding the door in place, tighten the top hinge screws. Do not overtighten these screws. Tighten
them until they are just snug, and then turn another half a turn.
3. Snap the left top hinge cover into place.
(left top hinge and cover can be found are supplied with the unit's
