9.5 Messages from PC to Keyboard

All the messages transmitted from the PC to the keyboard are confirmed by the DCZ keyboard by an
acknowledge message. The messages from PC to Keyboard are:
COMMAND
[Status?]
[Model?]
[Firmware?]
[Date?]
[Led+rc]
[Led-rc]
[Led-Al]
[Led/rc]
[LedRowrsssssssss]
[LedImmediate]
[LedDelayed]
[LedUpdate]
[LedCopy]
[Buzzer+]
[Buzzer-]
[Buzzer/]
[Orientation±]
[JoyDirX±]
[JoyDirY±]
[JoyDirZ±]
[LookupWriterc,val]
[LookupReadrc]
[BlockModeStart]
[BlockModeEnd]
Tab. 03 * The coordinates refer to the logical address of the LEDs, and not the value set in the lookup chart.
14
ACKNOWLEDGMENT
BY DCZ
[Ready]
[Model=...]
[Firmware=...]
[Date=...]
[LedrcSet]
[LedrcSet]
[LedAlSet]
[LedrcSet]
[LedRowSet]
[LedImmediateSet]
[LedDelayedSet]
[LedUpdateDone]
[LedCopyDone]
[BuzzerSet]
[BuzzerSet]
[BuzzerSet]
[OrientationOk]
[JoyDirOk]
[Lookup(rc)<-val]
[Lookup(rc)=val]
[BlockModeStart]
[BlockModeEnd]
MEANING
Keyboard online presence test
Keyboard model and firmware version
Led on
rc: Row 1...8 column 1...9*
Led off
rc: Row 1...8 column 1...9*
Switching off all LED's
Led blinking
rc: Row 1...8 column 1...9*
Led row setting
r: Row 1..8
sssssssss: LED row status (+ on. – off, / blinking).
Immediate LED
("9.6 LED updates", page 15)
Delayed LED update
("9.6 LED updates", page 15)
LED update
("9.6 LED updates", page 15)
LED status copy
("9.6 LED updates", page 15)
Start buzzer
Stop buzzer
Alternated start buzzer
Keyboard orientation:
+ Joystick on the right, jog shuttle on the left
- Joystick on the left, jog shuttle on the right
Positive direction of the joystick axis: allows you to invert the
direction of the individual joystick axis.
X+: To the right (default), X-: To the left
Y+: Upwards (default), Y-: Downwards,
Z+: Clockwise (default), Z-: Counter clockwise
Definition of the val value for the rc key* in the lookup chart
("9.7 Lookup chart (for experts only)", page 15)
Lookup value read set for a logical coordinate key rc* ("9.7
Lookup chart (for experts only)", page 15)
This allows you to modify the configuration without using the
memory following multiple changes in values
This saves the last modified values [BlockModeStart]
