- Page 1 SPRING Design by LUNDBERGDESIGN Istruzioni di montaggio Assembly instructions Montageanleitung Instructions de montage Instrucciones de montaje More details at: platek.eu/SPRING...
- Page 2 18 Led 40,5W 220-240V 0/50/60Hz 6,1 Kg 18 Led RGB 40,5W max 500mA 6,1 Kg HIT-TC-CE 20W G8,5 220-240V 0/50/60Hz 4,8 Kg HIT-TC-CE 35W G8,5 220-240V 0/50/60Hz 4,8 Kg HIT-TC-CE 70W G8,5 220-240V 50/60Hz 4,8 Kg 2 PLATEK - USER GUIDE...
- Page 3 Installation width: any 15° SPRING floodlight 195° 195° 15° 15° 195° 15° 195° 195° 15° Superficie esposta al vento Altezza di installazione: Qualunque 15° 0,045 m Surface exposed to wind Installation width: any 195° 15° 3 PLATEK - USER GUIDE...
- Page 4 SPRING INSTALLATION TECHNICAL DATA MICRO SPRING CH 2,5 1,2 Nm MINI SPRING / SPRING CH 4 2 Nm 4 PLATEK - USER GUIDE...
- Page 5 Conector suministrado ≥IP65 SPRING Ø cables 8-13 mm H07RN-F <HAR> Micro SPRING / Mini SPRING Ø cables 6-10 mm H07RN-F <HAR> Per l’alimentazione utilizzare solo il cavo fornito con l’apparecchio To power the product use exclusively the supplied cable Fuer die Versorgung nur die beigefuegte Zuleitung benutzen Pour l’alimentation utiliser exclusivement le câble livré...
- Page 6 SPRING INSTALLATION TECHNICAL DATA ONLY FOR LAMP SPRING / MINI SPRING CH 4 6 PLATEK - USER GUIDE...
- Page 7 SPRING INSTALLATION TECHNICAL DATA ONLY FOR LAMP SPRING / MINI SPRING Connettore fornito Connector supplied Kabelverbinder inklusive Connecteur fourni ≥IP65 Conector suministrado Per l’alimentazione utilizzare solo il cavo fornito con l’apparecchio To power the product use exclusively the supplied cable Fuer die Versorgung nur die beigefuegte Zuleitung benutzen Pour l’alimentation utiliser exclusivement le câble livré...
- Page 8 SPRING INSTALLATION TECHNICAL DATA ONLY FOR LAMP SPRING / MINI SPRING CH 4 2 Nm 8 PLATEK - USER GUIDE...
- Page 9 SPRING ACCESSORIES TECHNICAL DATA FILTER SPRING / MINI SPRING 9 PLATEK - USER GUIDE...
- Page 10 SPRING ACCESSORIES TECHNICAL DATA POLE SPRING / MINI SPRING Ø 60 Ø 102 Ø 114 CH 5 3 Nm CH 8 3 Nm 10 PLATEK - USER GUIDE...
- Page 11 SPRING ACCESSORIES TECHNICAL DATA POLE SPRING / MINI SPRING 11 PLATEK - USER GUIDE...
- Page 12 T + 39 030 6818201 Ottieni supporto tramite telefono o E-mail, E-MAIL INFO@PLATEK.EU WWW.PLATEK.EU contattandoci al +39 030 68 18 201 o scrivendo all’indirizzo E-mail supporto@platek.eu REGISTERED OFFICE: HOW CAN WE HELP YOU? VIA PADERNO 19 25050 RODENGO SAIANO Get support by phone or e-mail, call us on...
