Figure 3
C
(A) Place frame over top of tabs.
(B) Push in at bottom until frame is flush with front panel.
(C) Insert two screws to hold frame in place.
Operation and
WARNING: This heater must be properly installed before
it is used.
WARNING: Disconnect power and heater has cooled
before attempting any maintenance or cleaning to reduce
the risk of fire, electric shock or damage to persons.
!
NOTE: This heater should not be operated with an ac-
cumulation of dust or dirt on or in the unit, as this can cause
a build up of heat and eventual damage. For this reason the
heater must be inspected regularly, depending upon condi-
tions and at least at yearly intervals.
1. Set thermostat to desired temperature and both fan and
heat should come on. Note that when desired tempera-
ture is reached the fan operation will continue for a short
period after the elements have de-energized in order to
remove residual heat from the unit.
2. The fan motor is permanently lubricated and sealed at
the factory and is maintenance free.
3. It is suggested that at the beginning of each season the
front panel is removed and the wire connection condition
is checked and the unit is cleaned of dust and dirt with a
vacuum cleaner.
WARNING: Should the Over Temp light come on, discon-
nect power to the heater or turn down the thermostat fully
counterclockwise and call a licensed electrician. DO NOT
USE HEATER UNTIL PROBLEM IS DETERMINED AND
FIXED.
1367 Industrial Road Cambridge ON Canada N3H 4W3
1-888-346-7539 www.dimplex.com
In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice.
© 2016 Dimplex North America Limited
A
C
B
Maintenance
Warranty
The Manufacturer warrants the heating elements and components
of the enclosed product against any defect in material or
workmanship for a period of one year from the date of purchase. In
full satisfaction of any claims under this Warranty the Manufacturer
will repair or replace without charge, in its factory or in the field as it
alone may decide, any parts which in its opinion are defective.
The Manufacturer shall not be responsible for any transportation
or shipping costs in relation to such repair or replacement except
as specifically assumed by it. Misuse of this product or repairs by
persons other than the Manufacturer's authorized personnel without
the Manufacturer's written approval, will void this Warranty.
This Warranty is in lieu of all other warranties or conditions
whether express or implied including but not limited to those of
merchantability or fitness for purpose and shall constitute the sole
remedy of the Purchaser and the sole liability of the Manufacturer in
respect of the sale of the product, whether in the nature of breach or
breach of fundamental term, or of negligence or otherwise.
The Manufacturer shall not be liable for any special, indirect or
consequential damages or for any damages resulting from removal
or replacement of a heater subject to warranty claim without the
Manufacturer's authorization.
This Warranty is transferable by the original consumer purchaser of
the product. Any claims under this Warranty must be submitted in
writing to the Service Manager, Dimplex North America Ltd., 1367
Industrial Rd., Cambridge, Ontario N3H 4W3, Canada.
