RUE-4185
Remote Control Unit
Owner's Manual
Mode d'emploi
Mute Button
Press the button to lower the volume
by 20 dB instantly. Press the button
again to cancel.
Volume Adjustment Buttons
To increase the volume level.....
Power Switch
Press the
Press the switch to turn the power
To decrease the volume level.....
on/off.
Press the
k Button
Press the button to switch between the
Play and Pause modes for the tape
player or CD.
CD Changer Button
Press the button to change to the CD
changer operation.
Band/Program Button
Radio mode: BAND Button
Tape mode: Program Button
Button
Radio mode: Pressing the button will
select, in ascending order, stations
programed into the radio's presets as
shown below.
→1 →2
6
• • •
Tape mode: Pressing this button
enters the Program Sensor Up mode.
This allows for music selection towards
the end of the tape.
CD/CD Changer mode: DISC Select
(UP) Button
Press the button to select a disc in
ascending order.
Equalizer/Surround mode: After
calling each mode with the A. PROC
button, press the button to select
each mode.
All manuals and user guides at all-guides.com
R
Button
Radio mode: SEEK (DN) Button
Tape mode: REW Button
CD/CD Changer mode: Press the
button to go back to the beginning of
the current track.
Button
Radio mode: SEEK (UP) Button
Tape mode: FF Button
CD/CD Changer mode: Press the
button to advance to the beginning of
the next track.
button
Button
button
Radio mode: Pressing the button will
select, in descending order, stations
programed into the radio's presets as
shown below.
→6 →5
Tape mode: Pressing this button
enters the Program Sensor Down
mode. This allows for music selection
towards the beginning of the tape.
VOLUME
CD/CD Changer mode: DISC Select
MUTE
(DN) Button
Press the button to select a disc in
PWR
descending order.
Equalizer/Surround mode: After
ENT
calling each mode with the A. PROC
button, press the
CD-CHG
each mode.
BAND
SOURCE A.PROC
PROG
Audio Processor Button**
Press the button to call the external
REMOTE CONTROL UNIT
audio processor mode*.
Audio Select Button
Press to select the audio source.
* For the operation of external
audio processor, refer to the
Owner's Manual of the external
audio processor you purchased.
** This button is used in conjunction
with an optional Ai-NET processor.
Handling Precautions
Do not drop or apply shock to the unit. It may get
permanently damaged.
Keep the unit away from water and moisture, direct sun
and heat, and excessive dust.
Never use scouring pads, steel wool, abrasive powders or
harsh chemical agents, such as lye solution, for cleaning.
Battery Replacement
Applicable battery: Use two "AAA" sized dry batteries or equivalent.
1. Opening the battery cover
Slide out the battery cover while firmly
pressing outward.
In Case of Difficulty
Problem Cause
Remote Reverse
1
• • •
Control placement of
Inoperative. battery.
Dead battery.
Remote Control
not pointed
towards the head
unit.
button to select
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku, Tokyo 141, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
Clean with a soft, lint-free cloth or cotton swab slightly
dampened with a mild solution of detergent and water.
Do not operate this unit in a manner that could distract you
from driving safety.
2. Replacing the battery
3. Closing the cover
Put the batteries in the case as
illustrated.
e
d
d
e
Specifications
Battery Type ........................................ "AAA" sized dry battery
Solution
Battery Quantity ..................................................................... 2
Place the battery correctly
Dimensions (W x H x D) ........... 56mm (2-1/4") x 14mm (9/16")
into its cradle and back in
the compartment.
Weight (without battery) .......................................... 50 g (1 oz)
Replace the battery with a
new one.
Point the unit directly
toward your head unit.
R
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L.
6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)
Victoria 3173, Australia 98, Rue De La Belle Etoile, Z.I. Paris Nord II
B.P. 50016 F-95945, Roissy,
Tel.: (03) 9769-0000
Charles de Gaulle Cedex, France
ALPINE ELECTRONICS GmbH
Tel.: 01-48 63 89 89
Brandenburger Strasse 2-6 D-40880 Ratingen,
ALPINE ELECTRONICS OF U. K., LTD.
Germany
Tel.: 02102-45 50 13 Tanners Drive, Blakelands,
Milton Keynes MK14 5BU, U.K.
ALPINE ITALIA S.p.A.
Tel.: 01908-61 15 56
Via C. Colombo 8, 20090 Trezzano Sul
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Naviglio MI, Italy
Tel.: 02-48 40 16 24 Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava) - Apdo. 133, Spain
Tel.: 34-45-283588
Push the cover as illustrated until a
click is heard.
x 105mm (4-1/8")
68P11199Y20-O
Printed in Japan (S)
