Dimmer function for the remote control
Switch the dimmer on (available as an option) by pressing the ON button briefly, for the corresponding
switching channel, once.
Press the ON key for the corresponding switching channel. The dimmer function starts.
Press the ON key for the corresponding switching channel again. The dimmer function stops.
Start-up, function test
Set the correct switching group on the remote control, using the "Selector switch for switching group" (2).
Plug the radio controlled socket (without the consumer load connected!) into the designated earthed mains
socket.
You can now test the function of the radio controlled mains socket, by briefly pressing the respective "ON"
button for the corresponding switching channel (1, 2, 3 or 4). The red LED "ON/OFF/INDICATOR" (6) on the
radio controlled socket lights up. The socket (7) on the front is now activated; the mains voltage is available
and a connected consumer load is turned on.
Briefly press the "OFF" button, for the switching channel, and the "ON/OFF/INDICATOR" (6) LED goes out;
the mains voltage to the front socket (7), and thus the connected consumer load, is turned off.
Operation
Connect a consumer load to the front socket (7).
Please consult the section "Technical Data" for the permissible maximum power.
By using the respective "ON" or "OFF" button for the switching channel on the hand-held radio transmitter,
the radio controlled socket, set to the same switching channel, is turned on (the LED "ON/OFF/INDICATOR"
(6) lights up) or off (the LED "ON/OFF/INDICATOR" (6) goes out) .
Maintenance and care
The product does not require any maintenance and should never be opened or disassembled for any reason.
Remove connected consumer loads from the radio controlled socket and remove it from the mains socket,
before cleaning the product.
Only clean the product with a soft, clean, dry cloth. Never use aggressive cleaning agents or chemical solu-
tions since these might damage the surface of the casing or impair the operation.
Handling
• The radio remote control and the radio controlled sockets are only intended for use in dry
indoor locations.
• Avoid the following unfavourable environmental conditions at the installation location and dur-
ing transportation:
- Moisture and damp
- Direct sunlight
- Extreme cold or heat
- Dust or flammable gases, fumes or solvents
- Strong vibrations
- Strong magnetic fields such as those found in the vicinity of machinery or Loudspeakers
• Ensure that the insulation for the entire product is neither damaged nor destroyed. Never
disassemble the product! The casing does not contain any serviceable parts.
• Check the product for damage before each use!
If you notice any damage, do not use the product any longer!
There is a risk of a life-threatening electric shock!
Safe operation must be presumed to be no longer possible:
- if the device is visibly damaged
- if the device no longer works
- if the device was stored under unfavourable conditions for a long period of time
- if it was exposed to extraordinary stress caused by transport
Range
The transmission range of the radio signals between the hand-held radio transmitter and the radio controlled
sockets is up to 70 m under optimum conditions.
This value, however, is the so-called "open space range" (the range when transmitter and
receiver are visible to each other, without interfering influences).
In practical operation, however, there are walls, ceilings of rooms etc. between the trans-
mitter and the receiver, which reduce the range accordingly.
Due to the different influences on the radio transmission, no specific range can be guar-
anteed.
Nevertheless, trouble-free operation in a single-family home is usually possible.
The range can sometimes be limited considerably by:
• walls, reinforced concrete ceilings
• coated/metallised insulated glass
• proximity to metal & conducting objects (e.g. radiators)
• proximity to human bodies
• Broadband interferences, e.g. in residential areas (DECT telephones, mobile phones, radio-controlled
headphones, radio-controlled speakers, radio-controlled weather stations, baby phones etc.)
• Proximity to electric motors, transformers, power-supply units, computers
• The proximity to improperly shielded or uncovered operating computers or other electric appliances
Disposal
a) General Information
Please dispose of the device when it is no longer of use, according to the current statutory
requirements.
b) Batteries and Rechargeable Batteries
As the end user, you are required by law (Battery Ordinance) to return all used batteries/rechargeable bat-
teries; disposal of them in the household waste is prohibited!
Batteries that contain pollutants, or rechargeable batteries with the symbol depicted here, can-
not be disposed of with the normal household garbage. The designations for the heavy metals
involved are: Cd = cadmium, Hg = mercury, Pb = lead.
Used batteries, rechargeable batteries as well as coin cells can be returned to collection points in your
municipality, our stores or wherever batteries/rechargeable batteries/coin cells are sold!
You thus fulfil the legal requirements and make your contribution to protecting the environment!
Declaration of Conformity (DOC)
We, Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that the product
conforms to the fundamental requirements and the other relevant regulations of Directive 1999/5/EC.
You can find the declaration of conformity at www.conrad.com.
Technical data
a) Radio controlled handheld transmitter
Transmission frequency...............433 MHz
Power supply ...............................1 x 12 V battery, type "23 A"
Range ..........................................Up to 70 m (open space, see chapter "Range")
LED ..............................................Lights up briefly, when the buttons are used
Switching groups .........................4
Programmable receivers or .........
Number of switching channels .....16
Operating temperature ................0 °C to +35 °C
Dimensions (L x W x H) ...............approx. 105 x 43 x 22 mm
b) Radio controlled socket
Reception frequency ....................433 MHz
Operating voltage ........................230 V/AC, 50 Hz
Protection class ...........................I
Connected power ........................max. 2000 W Ohm resistive load (internal thermal fuse)
LED ..............................................Lights up, when the mains socket/consumer load is activated
Dimensions (L x W x H) ...............approx. 116 x 58 x 73 mm
Up to 10 radio channels can be programmed for the radio controlled socket.
