Elkron RC200 Guide Rapide

The Remote Controller is used to arm the system in home or away mode, disarm the system and
GB
send a panic signal.
IDENTIFYING THE PARTS
BUTTON
Pressing this button will arm the system in away mode.
BUTTON
Pressing and holding this button for three seconds will send a panic signal, regardless of system
status (armed or disarmed). If the 3 seconds time is not reached, the Emergency activation will fail.
N.B.
Panic alarm cannot be stopped after activation by pressing disarm button on Remote Controller. To
stop the alarm, the disarm command must be sent from a keypad or a second Remote Controller.
However the alarm will stop once reached the configured alarm time out.
BUTTON
Pressing this button will arm the system in home mode.
BUTTON
Pressing this button will disarm the system. If the alarm is sounding, pressing this button will stop
the alarm (except when the alarm situation was caused by pressing the Panic button on Remote
Controller).
TX INDICATOR
The red LED will turn on for every successful transmission. When pressing the Panic button, the TX
LED will stay on for one second to indicate a successful transmission.
Note:
On pressing of Panic button, the TX LED will first flash for three seconds and then stay on to indicate
a successful transmission.
BATTERY COMPARTMENT
The Remote Controller uses one CR2032 3V 230 mAh Lithium battery as its power source. The
Remote Controller will have a typical battery life of over 2 years at a normal domestic environment.
The low battery status will be sent to the Control Panel along with regular signal transmission, and,
the Control Panel will display the status accordingly.
Note:
When changing battery, after removing the old battery, press any button twice to fully discharge
before inserting new battery.
REMOTE CONTROLLER (RC200)
TÉLÉCOMMANDE (RC200)
FERNBEDIENUNG (RC200)
