FRONT PANEL

TALKBACK
sens
+ +
1
1 2
1 - Led indicator for triggering the talkbak 1.
2 - Setting the input level of order 1. (Cermet multiturn potentiometer)
3 - Led indicator of the triggering of the talkback 2.
4 - Setting the input level of order 2. (Cermet multiturn potentiometer)
5 - Volume of the headphone 1.
6-8-10-12-14 - Modulation selector for output N (N from 2 to 6)
 Switch pressed: N-1 Coupled = Same modulation as the previous channel (N-1).
 Switch off:
7-9-11-13-15 - Volumes of the headphone 2 to 6.
16 - Power on indicator.
Rami
HEADPHONE 1
sens
+
0 10
VOLUME
2
3 5
4
Rear in N = Direct input for the N channel on the rear panel.
HEADPHONE 2 HEADPHONE 3 HEADPHONE 4
1 Coupled 2 Coupled 3 Coupled
Rear IN2 Rear IN3 Rear IN4
0 10 0 10 0
VOLUME VOLUME VOLUME
6 7 8 9 10
11
14
HEADPHONE 5 HEADPHONE 6
4 Coupled 5 Coupled
Rear IN5 Rear IN6
10 0 10 0 10
VOLUME VOLUME
13 15 16
12 14

On
6 VCA Headphones Amplifiers
AMC625
