FRONT PANEL

1 -
Left A channel level setting ranges from 0 to +22 dB.
2 -
Right A channel level setting ranges from 0 to +22 dB
3 -
Left B channel level setting ranges from -28 to -6 dB.
4 -
Right B channel level setting ranges from -28 à -6 dB.
5 -
Power supply light indicator.

JUMPERS

RCS3008A
Rami
3
1
2
4
CAUTION 230VAC
+
+
Fus T-160mA L
11
5
.
JP3 / JP4 : A section
P
N
+
+
JP1 / JP2 : B section
P
N
Switch to stereo
Switch to mono
Switch to stereo
Switch to mono
TUS404
