At the selected program function to be changed, if the throttle stick is stayed at the full power position for
over 4 seconds, the red and green LED should flash to indicate that you can now change an existing
parameter to a new parameter. In order to change the existing parameter, move the stick to the minimum
or lower position then again to the full power position. The selected parameter will indicate as follows.
1 Motor Type
2 Battery Type
3 Cut Off Voltage
4 Power Curve
5Advance Timing
6 Acceleration
7 Start Power
8 Reverse Function
9 Reverse Delay
10 M-Reverse Amount
11 Neutral Width
12 Speed Mixing Brk
13 A.B.S Brake
14 Auto Brk Amount
15 Min Brake Amount
16 Max Brake Amount
17 Factory Setting
The inside number of the brackets above is the number of the LED flashing.
The cutoff voltage in automatic mode is as like:
LiPo : the higher voltage between 5.5V and 66% voltage when the switch is on
-
LiFe : the higher voltage between 5.0V and 67% voltage when the switch is on.
-
NiMh/ NiCd : the higher voltage between 4.0V and 50%voltage when the switch is on.
-
After you select your wanted parameter, stay the throttle stick at the neutral position for over 4 seconds,
the red LED should flash and the motor should beep (Mi, Re, Do, Re, Mi sound) to indicate that the
selected parameter is stored at the ESC and other parameters can be selected.
After changing all parameters, if the button is shortly pressed, the ESC is now in standby mode.
At this stage, if you want to change another program parameter, repeat the procedure above, or if all
settings are complicated, turn off the speed controller.
• The ESC status when the ESC is powered on through by the setup button.
Sensorless
Brushless sensorless(1) / Brushless sensored(2) / Brushed(3)
LiPo(1) / LiFe(2) / NiMh (NiCd) (3)
Auto(1) / 3.0V(2) ~ 9.0V(14)
Soft (1) / Linear(2) / Hard(3)
0`(1) ~ 25`(6) / 0(1) ~ 10(6)
Lowest(1) / Low / Normal / High / Highest(5)
Lowest(1) / Low / Normal / High / Highest(5)
One Way(1) / Two Way1(2) / Two Way2(3)
0.2s(1) / 0.5s / 0.8s / 1.3s / 1.8s / 2.5s (6)
20%(1) ~ 100%(9)
Narrow(1) / Normal(2) / Wide(3)
0%(1) ~ 100%(11)
Off(1) / Weakest / Weak / Normal / Strong / Strongest(6)
0 % (1)
~ 100% (11)
0 % (1)
~ 100% (11)
0 % (1) ~ 100% (11)
All parameters to be initialized as factory default values(2)
Sensored
(0.5V steps)
Brushed
Defalut
Sensored
LiMh
Auto
Linear
25' / 10
Highest
Highest
Two Way 2
2.5s
60%
Normal
0%
Off
0%
30%
100%
