SECTION 5 |
PUSH: Display Select
LCD Display – Fault Messages
The LCD display indicates the following fault messages when SCC-30AB stops operating.
32 | SAMLEX AMERICA INC.
Construction, Layout & Controls
Display Screens (1, Fig 5.1)
Amp Watts BatV
0.0 0.0
PUSH: Display Select
Amp-Hours
0 Ah
PUSH: Display Select
Total Amp-Hours
0 Ah
PUSH: Display Select
Mode: Charger
State: Bulk or Absorption or
Float or Equalization
PUSH: Display Select
Bulk*
14.0V
PUSH: Display Select
EQU EQU-T CYCLE
14.2V 1hr
PUSH: Display Select
Heatsink BTS
25 o C
Fig. 5.3. LCD Display Flow
12.0
Float
13.4V
* Note: Displayed as "Bulk".
Actually, it is "Absorption".
28day
25 o C
Screen 1
Screen 2
Screen 3
Screen 4
Screen 5
Screen 6
Screen 7
