installation instructions
1. Remove contents from carton.
2. Assemble frame by inserting armrest section into two
frame support sections by depressing brass push
pins on armrest and inserting into receptacles. Note
that front of armrest should correspond to section
with rubber tips. When in place, push buttons with
snap into place. Insert "E" clip into back of frame to
secure armrest to frame. Repeat for second armrest.
(Figure 1)
FRONT
Figure 1
3. Remove existing toilet seat from toilet. Be sure to
save the existing screws as they will be needed to
attach the frame bracket and re-attach the seat.
(Figure 2)
Figure 2
REV4.04.22.14
"E" Clips
BACK
4. Place frame bracket on toilet with tube on bracket
closest to tank. Position toilet seat and cover over
the frame bracket and secure in place using the
screws mentioned in step 3. (Figure 3)
Figure 3
5. Insert armrest into the now-attached frame bracket,
making sure push pins protrude all the way through
the adjustment holes. Armrests can be adjusted by
depressing push pins and setting to desired width.
(Figure 4)
Figure 4
