2

Technical Data

Nominal acceptance power ......... 800 W
Speed ......................................... 3600 min-1 ............ 6400 min-1
Drilling diameter .......................... Ø 25 – 67 mm ....... Ø 6 – 25 mm
Drilling range .............................. Masonry Ø 40 x 400 mm
Tool fitting ................................... Quick change adapter with G 1/2" fitting
Weight ........................................ approx. 3,4 kg; Ceramic ECO approx.3,2 kg
Vibration ..................................... 2,6 m/s2
Drill bit types ............................... High Speed Plus, No. FF44806 – FF44868
Class of protection ....................... I
Noise pressure level (L
Sound power level (L
The noise level during operation can exceed 85 dB (A). Wear hearing protection!
Measured values determined in accordance with EN 60745-1:2010.
3

Electric supply

Only connect to one-phase alternating current and to the mains voltage indicated on the power
rating plate.
3.1

Putting the PRCD switch into operation

Only suitable for AC current! Note the mains network voltage!
Perform the following test procedure on the PRCD switch before every putting into operation of
the device:
1. Connect the PRCD plug connector with the socket.
2. Press on RESET. The indicator switches to ORANGE (ON).
3. Pull the plug connector out of the socket. The display switches itself off.
4. Repeat 1. and 2.
5. Press on TEST. The orange indicator switches itself off.
6. Press on RESET to switch the device on (ORANGE).
These protective device protect against faults in the attached device, not against such
faults in the preceding plant.
12
1. Gear
Concrete Ø 35 x 150 mm
Tile Ø 6 – 67 mm
SPEED STAR DX, No. FF00610 – FF00665
) ........... 91 dB (A) ¦ K
pA
) ............. 102 dB (A) ¦ K
WA
ENGLISH
2. Gear
3 dB (A)
pA
3 dB (A)
WA
