Technical Data - Hanhart DELTA E 200 SPECTRON Manuel D'instructions

Technical Data

Temperature range
In use: -15° C to +55° C
In storage: -25° C to +65° C
Battery
Type: Micro cell AAA
Capacity: About 5 - 6 years
Indicator: When the battery symbol appears in the display, there
is sufficient power for approximately another 3 months
Display
15 digits, 7mm digit-height
A window for functions indicator and battery indicator
Split 9 h, 59 min, 59 sec, 99/100
Lap 59 min, 59 sec, 99/100
Event-Count max. 99
Additionally on DELTA E 200:
Pacer 1 to 300 tones/min
Count-Down 59 min, 59 sec, 9/10
Additionally on SPECTRON:
Count-Down 59 min, 59 sec, 9/10
or 9999 min, 99/100 min
Case
made of ABS, water resistant ace. to DIN 8310
Weight
85g
Accuracy
+/- 7 sec / month
Measuring units
DELTA E 200
SPECTRON
11
= 7 digits lower row
= 6 digits upper row
= 2 digits middle row
= 3 digits upper row
= 5 digits upper row
= 5 digits upper row
= 5 digits upper row
1/100 sec
1/100 sec + 1/100 min
Memories
65
Functions
Start/Stop, Split/Lap, Short/Lap, Time, Memory-Recall
with evaluation of the shortest and longest LAP Time,
CD (Count-Down),
Additionally for DELTA E200: Pacer
Additionally for SPECTRON: Selectable time measuring
Keys
4
START/STOP,
SPLIT/LAP,
MEM/SET/DISP,
MODE
Changing the battery
Remove the back of the case (7 screws).
Install the new battery, observing the correct polarity! After changing a
battery, the date and time must be inserted again.
Legend explaining the various technical terms
SPLIT: Is the time accumulated after each point in time.
The last Split Time is also the total time.
LAP: Is the difference in time between the previous point in
time measured and the current time.
SHORT: Is the shortest Lap Time measured.
CD: Count-Down (counting down from the highest value)
PACER: Pace-setter (the number of tones per minute)
Memory: The time values in the memory.
START
SPLIT
STOP
LAP
SPLIT - SET
M-OUT
SHORT
PAC CD DAT TIME S-LAP
SPLIT
SET FAST MODE RESET
DISP
MEM
units
12
