INSTALLATION INSTRUCTIONS
INSTALLING THE REFRIGERATOR (Cont.)
REMOVING FREEZER DRAWER
IMPORTANT NOTES
When removing freezer drawer:
• Read the instructions all the way through
before starting.
• Provide a non-scratching work surface for the
doors.
REMOVE THE BASKETS
1
Open the freezer drawer until it stops.
A
Pull the top basket out until it stops. Lift the
B
basket up on the front and out to remove
The lower basket rests on a frame inside the
C
freezer drawer. Lift the front of the basket and
pull it forward. Release the pins from the slots
on the frame to remove the basket.
10
REMOVE THE DRAWER FRONT
2
Remove the screw on each side of the railing.
A
.
Lift up on both sides of the freezer drawer
B
handle to separate the drawer railings from
the rail assemblies.
Set the drawer front on a non-scratching
C
surface.
D Push the rail assemblies back into locking
position.
Screw
Drawer
Assembly
Rail
Assembly
