SPECIFICATIONS
(Information in brackets { } refer to TX-25LD90F)
Power Source:
Power Consumption:
Aerial Impedance:
Standby Power Consumption:
Receiving System:
Receiving Channels:
VHF E2-E12
VHF A-H (ITALY)
VHF R3-R5
UHF E21-E69
CATV S1-S10 (M1-M10)
CATV S21-S41 (HYPERBAND)
Intermediate Frequency:
Video
Sound
Colour
Video/Audio Terminals:
AUDIO MONITOR OUT
AV1 IN
AV1 OUT
AV2 IN
AV2 OUT
AV3 IN
High Voltage:
Picture Tube:
Audio Output:
(Music Power)
Headphones:
Accessories supplied:
Dimensions:
Height:
Width:
Depth:
Net Weight:
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
NOTE:
This Service Manual should be used in conjunction with the
EURO5 technical guide.
220-240Va.c., 50Hz
140W {130W}
75Ω unbalanced, Coaxial Type
1,9W
PAL-I, B/G, H, D/K, PAL-525/60
SECAM L/L', B/G, D/K
M.NTSC
NTSC (AV only)
VHF H1-H2 (ITALY)
VHF R1-R2
VHF R6-R12
CATV (S01-S05)
CATV S11-S20 (U1-U10)
38,9MHz, 34MHz
32,9MHz, 33,4MHz, 33,16MHz
32,4MHz, 40,4MHz, 33,05MHz
32,66MHz
34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
Audio (RCAx2)
500mV rms1kΩ
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 10kΩ
RGB (21 pin)
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 1kΩ
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 10kΩ
S-Video IN
Y: 1V p-p 75Ω
(21 pin)
C: 0,3V p-p 75Ω
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 1kΩ
Selectable Output (21 pin)
S-Video IN
Y: 1V p-p 75Ω
(4-pin)
C: 0,3V p-p 75Ω
Audio (RCAx2)
500mV rms10kΩ
Video (RCAx1)
1V p-p 75Ω
28,5kV ±1kV
A66ECF61X81
{A59ECF50X81}
2 x 20W
Left/Right
8Ω Impedance
8Ω Impedance
Remote Control
2 x R6 (UM3) Batteries
596,5mm
{550,5mm}
778mm
{730mm}
481mm
{478,5mm}
33kg
{28kg}
Colour Television
EURO - 5 Chassis
CARACTÉRISTIQUES
(Les informations entre parenthèses { } concernent le TX-25LD90F)
Alimentation:
Consommation:
Impédance d'antenne:
Standby Consommation:
Systéme de réception:
Canaux de réception:
VHF E2-E12
VHF A-H (ITALY)
VHF R3-R5
UHF E21-E69
CATV S1-S10 (M1-M10)
CATV S21-S41 (HYPERBAND)
Fréquency Intermédiaire:
Video
Sound
Couleur
Les bornes vidéo/audio:
SORTIE AUDIO MONITOR
Entrée AV1 (21 brioches)
Sorties AV1 (21 brioches)
Entrée AV2 (21 brioches)
Sorties AV2 (21 brioches)
Entrée AV3
Tension d'anode:
Tube image:
Sortie Audio:
(Music Power)
Casque d'écoute:
Accessories fournis:
Dimensions:
Hauteur:
Largeur:
Profondeur:
Poids (NET):
Les caractéristiques techniques sont susceptibles de modification sans
Préavis.
Le poids et les dimensions indiqués sont approximatifs.
ORDER No. SM-98067
TX-28LD90F
TX-25LD90F
220-240V a.c., 50Hz
140W {130W}
75Ω asymétrique sur prise coaxiale
1,9W
PAL-I, B/G, H, D/K, PAL-525/60
SECAM L/L', B/G, D/K
M.NTSC
NTSC (Entrée AV seulement)
VHF H1-H2 (ITALY)
VHF R1-R2
VHF R6-R12
CATV (S01-S05)
CATV S11-S20 (U1-U10)
38,9MHz, 34MHz
32,9MHz, 33,4MHz, 33,16MHz
32,4MHz, 40,4MHz, 33,05MHz
32,66MHz
34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM)
Audio (RCAx2)
500mV rms1kΩ
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 10kΩ
RGB (21 pin)
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 1kΩ
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 10kΩ
S-Video IN
Y: 1V p-p 75Ω
(21-pin)
C: 0,3V p-p 75Ω
Video (21 pin)
1V p-p 75Ω
Audio (21 pin)
500mV rms 1kΩ
Être sélectionnée
S-Video IN
Y: 1V p-p 75Ω
(4-pin)
C: 0,3V p-p 75Ω
Audio (RCAx2)
500mV rms10kΩ
Video (RCAx1)
1V p-p 75Ω
28,5kV ±1kV
A66ECF61X81
{A59ECF50X81}
2 x 20W
Gauche/Droite
8Ω Impédance
8Ω Impédance
Télécomande
R6 (UM3) x 2 Piles
596,5mm
{550,5mm}
778mm
{730mm}
481mm
{478,5mm}
33kg
{28kg}
