# Icon Item
3 Optical drive
Optical disk
4
access indicator
Optical drive eject
5
button
Emergency eject
6
hole
7 DC-in jack

Base view

1
2
# Icon Item
Battery release
1
latch/lock
Description
Internal optical drive; accepts CDs or DVDs.
Lights up when the optical drive is active.
Ejects the optical disk from the drive.
Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the emergency
eject hole to eject the optical drive tray when
the computer is off.
Connects to an AC adapter.
Description
Releases the battery for removal.
Insert a suitable tool into the latch and slide
to release.
