Control lay out
1) ON/OFF power button
2) Air hose stored in side compartment
3) Coiled power cable on rear
4) Fused 12v DC plug
5) Valve connector
6) 3x Valve adapters clipped on rear
Compressor Operation –
Vehicle tyre inflation
Fig 1
Remove the Velcro retaining strap and uncoil all of the power cable on the rear of the
compressor, ensuring all the cable is unwound. Insert the 12v DC plug into the 12v
socket. (Fig 1)
Remove the dust cap from the tyre valve and store in a safe place.
Carefully pull out the air hose from the side of the compressor. Screw the valve
connector clockwise onto the tyre valve. Ensure the valve is correctly connected but do
not over tighten. (Fig 2)
Caution
: Only inflate products to the manufacturer's specifications. Vehicle
tyre pressures can generally be found in the handbook, on the door pillar or on
the inside of the fuel filler cap.
Push the ON/OFF for the compressor to start. When the pressure gauge reaches the
required value push the ON/OFF to turn OFF the compressor.
Replace the tyre valve dust cap.
Note:- The gauge on this compressor is for guidance only. Check pressure with a known
accurate gauge.
The compressor may be used without the engine running but this will drain the power
from the vehicle battery if used for long periods.
Inflatable & Leisure Inflation
Select the suitable adapter and screw into the valve connector.
Adapters are clipped onto the rear of the compressor under the coiled power cable.
Insert the connector adapter into the appropriate inlet of the inflatable
Plug the 12v DC plug into the vehicle 12v socket. (Fig 1)
Push the ON/OFF button to switch the compressor on.
4
Fig 2
3
5
6
1
2
