RUE-4202
Remote Control Unit
Owner's Manual
Controls on Remote Control
1
Source Button
Press to select the audio source.
2
Volume Adjustment Buttons
To increase the volume level:
Press the L button
To decrease the volume level:
Press the K button
3
8 Button
Radio mode: Pressing the button will select,
in ascending order, stations programed into the radio's
presets as shown below.
→ 1 → 2 ... 6
CD Changer mode: DISC Select (UP) Button
Press the button to select a disc in ascending order.
MP3/WMA mode: Folder Select (UP) button. Press this
button to select the folder.
MP3 compatible CD changer mode (while playing back
MP3):
Folder Select (UP) / DISC Select (UP) button
Press this button to select a folder in ascending order.
Press and hold this button to select a disc in ascending
order.
Tape mode: Pressing this button enters the Program
Sensor Up mode.This allows for music selection
towards the end of the tape.
Audio Processor Mode: Press this button to adjust the
MODE that is called by pressing the A.PROC. button.
4
g Button
Radio mode: SEEK (DN) Button
CD/CD changer mode: Press the button to go back to
the beginning of the current track.
Tape mode: REW Button
5
-/J Button
Press the button to switch between the Play and Pause
modes for CD or MD and Tape.
6
Audio Processor Button
Each press of the button changes the audio processor
mode.
Press 8 or 9 button to perform setting / adjustment.
R
Press the button to call the external audio processor
mode when the external audio processor is connected.
∗1
For the operation of external audio processor, refer to the Owner's
Manual of the external audio processor you purchased.
7
Power Button
Press the button to turn the power on/off.
8
Band Button
Radio mode: BAND Button
Changer mode: BAND Button
Switches changers (when a Multi-Changer Switching
device is connected).
Tape mode:
Press the button to change between the A and B side
of the tape.
9
f Button
Radio mode: SEEK (UP) Button
CD/CD changer mode: Press the button to advance to
the beginning of the next track.
Tape mode: FF Button
!
9 Button
Radio mode: Pressing the button will select, in
descending order, stations programed into the radio's
presets as shown below.
→ 6 → 5 ... 1
CD Changer mode: DISC Select (DN) Button
Press the button to select a disc in descending order.
MP3/WMA mode: Press the Folder Select (DN) button.
Press this button to select the folder.
MP3 compatible CD changer mode (while playing back
MP3 ):
Folder Select (DN) / DISC Select (DN) button
Press this button to select a folder in descending order.
Press and hold this button to select a disc in
descending order.
Tape mode: Pressing this button enters the Program
Sensor Down mode.This allows for music selection
towards the beginning of the tape.
Audio Processor Mode: Press this button to adjust the
MODE that is called by pressing the A.PROC. button.
"
Mute Button
• Press the button to lower the volume by 20 dB
instantly. Press the button again to cancel.
• Press the button for at least 2 seconds to raise the
monitor. Press the button again to lower the monitor.
(Head unit with Monitor Display, etc.)
•
Depending on the device you are using, you cannot operate or may need
to operate differently some devices on the remote control.
For details, refer to the Owner's Manual of the device you purchased.
Autogood products internet store http://130.com.ua
Handling Precautions
Do not drop or apply shock to the unit. It may be get
permanently damaged.
Keep the unit away from water and moisture, direct sun
and heat, and excessive dust.
Never use scouring pads, steel wool, abrasive powders or
harsh chemical agents, such as lye solution, for cleaning.
Battery Replacement
Applicable battery: Use two "AAA" sized dry batteries or equivalent.
∗1
1
2
Opening the battery cover.
Slide out the battery cover while
firmly pressing the direction of arrow.
In Case of Difficulty
Problem
Cause
Solution
Remove
Reverse
Place the battery
Control
placement of
correctry into its cradle
Inoperative.
battery.
in the compartment.
Dead battery.
Replace the battery with
a new one.
Remote Control not
Point the remote control
pointed toward the
directly toward your
head unit.
head unit.
R
ALPINE ELECTRONICS MARKETING, INC.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Fletchamstead Highway, Coventry CV4 9TW,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
DONGGUAN GAOQI PRINTING CO., LTD.
YANG WU NO.2 IND. DISTRICT DALING SHAN TOWN
DONG GUAN CITY GUANG DONG CHINA
Clean with a soft, lint-free cloth or cotton swab slightly
dampened with a mild solution of detergent and water.
Do not operate this unit in a manner that could distract
you from driving safety.
3
Replacing the battery.
Closing the cover.
Put the batteries in the case observing
Push the cover as illustrated
the polarities as illustrated.
until a click is heard.
Specifications
Battery Type ................................. AAA sized dry batteries
Battery Quantity ................................................................ 2
Dimensions(W x H x D) ........................... 42 x 121 x 22mm
(1-21/32" x 4-25/32" x 7/8")
Weight (without battery) .................................. 50g (1.8 oz)
Accessory ............................... Remote Control Unit Holder
ALPINE ELECTRONICS FRANCE S.A.R.L.
161-165 Princes Highway, Hallam
(RCS PONTOISE B 338 101 280)
Victoria 3803, Australia
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
Phone 03-8787-1200
B.P. 50016, 95945 Roissy Charles de Gaulle
ALPINE ELECTRONICS GmbH
Phone 01-48638989
Frankfurter Ring 117,
80807 München, Germany
ALPINE ITALIA S.p.A.
Phone 089-32 42 640
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
ALPINE ELECTRONICS DE ESPAÑA, S.A.
U.K.
Portal de Gamarra 36, Pabellón, 32
Phone 0870-33 33 763
01013 Vitoria (Alava)-APDO 133, Spain
Cedex, France
Phone 02-484781
Phone 945-283588
68-04123Z30-A
Printed in China(Y)
