SECTION 8 |

8.2 OVERALL DIMENSIONS

The overall dimensions and the location of the mounting slots are shown in
Fig. 8.1.1 for PST-600 and 8.1.2 for PST-1000:
15.2
3.8
32
12
162
12
32
1.6
Fig. 8.1.1: PST-600 Overall Dimensions & Mounting Slots (NOTE: Dimensions in mm)
30 | SAMLEX AMERICA INC.
Installation
200
NEG – NEG – POS +
WARNING:
Reverse polarity will damage the unit.
AVERTISSEMENT :
Inversion de polarité peut endommager l'unité.
238
15.2 3.8
9.5
5
276.2
82
