Troubleshooting

If you have problems with your system, look through this chart
and see if you can solve the problem yourself before calling your
dealer or TEAC service center.
No power
eCheck the connection to the AC power supply.
Cannot listen to any station, or signal is too weak.
eTune in the station properly.
eIf a TV is near the unit, turn it off.
eInstall the antenna again after locating the best reception
position.
eAn external antenna may be required.
Though the broadcast is stereo, it sounds monaural.
ePress the FM MODE button.
Remote control does not work.
eIf the batteries are exhausted, change the batteries.
eUse remote control unit within the range (5m/15ft) and point
at the front panel.
eClear obstacles between the remote control unit and the
main unit.
eIf a fluorescent light is near the unit, turn it off.
If normal operation cannot be achieved, unplug the power cord
from the outlet and plug it again.
28
FM Tuner Section
(Without notes 98 MHz, 65 dBf)
Tuning Range:
87.5 MHz – 108.0 MHz (100 kHz steps)
Usable Sensitivity (IHF):
Mono: 11.2 dBf
50 dB Quieting Sensitivity:
Mono: 15 dBf
Stereo: 20 dBf
Total Harmonic Distortion (1 kHz):
Mono: 0.4%
Stereo: 0.5%
Frequency Response: 30 Hz – 15 kHz, +1/ –1.5 dB
Stereo Separation (1 kHz): 40 dB
Signal-to-Noise Ratio:
Mono: 72 dB
Stereo: 70 dB
AM Tuner Section
Tuning Range:
530 kHz – 1,720 kHz (10 kHz steps)
Usable Sensitivity: 55 dB/m
Total Harmonic Distortion: 0.8% at 85 dB/m
Signal-to-Noise Ratio: 45 dB at 85 dB/m
General
Power Requirements:
120/230 V AC, 50-60 Hz
Power Consumption:
8 W
Dimensions (W x H x D)
435 x 102 x 270 mm
Weight (net): 3.6kg
Standard Accessories:
AM Loop Antenna x 1
FM T-type Antenna x 1
Matching Transformer x 1
Remote Control Unit (RC-789) x 1
< Improvements may result in specifications and features
changing without notice.
< Illustrations may differ slightly from production models.
ENGLISH

Specifications
