Vega Technologies AeroMEDIK Compact Mode D'emploi page 23

Specifications
7.
Power
Current
Medication Capacity
Particle Size
MMAD
Sound Level
Maximum Medication capacity
Average Nebulization Rate
Compressor Pressure Range
Operating Pressure Range
Liter Flow Range
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Storage Humidity Range
Dimension (L x W x H)
Weight
Protection against electric shock
Class II Equipment
Type BF applied parts: Mouth piece & mask.
Protection against harmful ingress of water : IPX0 (Ordinary)
Degree of safety in the presence of flammable anesthetics or oxygen : No AP/APG (Not suitable for use in the presence of flammable
anesthetics or oxygen)
Mode of operation – continuous.




WARANTY : 3 years starting at moment of purchase. It is absolutely necessary to keep your ticket.
AC 230V, 50Hz
0.8A
5ml
0.5 to 10 μ m
4 μ m
Around 60 dBA
13ml (cc)
0.2ml/min
30 to 36 Psi (210 to 250 KPa / 2.1 to 2.5 bar)
8 to 16 Psi (50 to 100Kpa / 0.5 to 1.0 bar)
6 ~ 8 lpm
10°C to 40°C (50°F to 104°F)
10 to 95% RH
-20°C to 70°C (-4°F to 158°F)
10 to 95 % RH
188 x 106 x 188mm (7.4" x4.1" x 7.4")
3.3Lbs (1.5kg)
