Instruction manual BES M18MH2-GNX80F-S04G-X04
Dimensions
M18x1
Connection diagram
intrinsically safe sensor
accord. to IEC 60947-5-6
Colour code BK: black | BN: brown | BU: blue | GY: grey | WH: white
Installation
BA-S36105-GB-2020-22
24
hazardous area
(1) BN
+
(2) WH
–
grounded metal frame
non hazardous area
BAE SA-XE-
+
***-XR-SA39
–
Type
M12x1
M18x1
M30x1,5
Page 3
Supply voltage
Relay output
max. torque
10 Nm
25 Nm
40 Nm
Dok.-Nr. 947414-EN/FR-E20
Subject to modification
