ION Block Rocker Sport Guide D'utilisation Rapide page 5

Features
1. Power Button: Turns Block Rocker
Sport on or off. Please note that
while Block
connected to a power source, it
does not need to be powered on to
charge the battery. When the
power is on, the display will show
the power indicator.
2. Bluetooth Button: Press the Bluetooth button to disconnect a paired Bluetooth device.
3. Light Mode Button: Press this button to select how the lights on the front panel function:
•
White: The lights are lit solidly white.
•
Color Cycle: The lights slowly glow and cycle through colors. Press and hold the light
mode button to freeze the lights on one color.
•
Beat Sync: The lights react to the beat of the music.
•
Off: The lights turn off. This is the default mode when Block Rocker Sport is first
powered on.
4. Radio Selector: This button sets the Radio to AM, FM, or turns the radio off.
5. AM/FM Presets: Store a favorite radio station and quickly tune to a preset radio station.
There are 6 numeric positions to store AM band presets and 6 numeric positions to store
FM band presets. To add a preset:
i. Select either the AM or FM band and then use the Tune/Track Buttons to select the
desired radio station.
ii. Press and hold a numeric preset button to assign the current station to that preset
number. The display will show "SAVE" to show the station has been saved. To use an
added preset, tap a preset number once lightly to go to the stored radio station.
6. Tune/Track Buttons: Tap these buttons to tune in a radio station or go to the
previous/next track on a Bluetooth connected device. To "seek" (jump to the next available
station), hold either button down for a few seconds until it starts to seek a station. The unit
will remember the last station it was on and start at that station when powered off and on
again.
7. Play/Pause: Press to play or pause a track from a connected Bluetooth device.
8. Display: Displays the current radio station, battery status, and Bluetooth status.
•
Charging Indicator: When the power cable is connected, movement of the top
battery segment shows the battery is charging. When fully charged, all battery
segments will be lit without blinking. When the power cable is disconnected, the
battery segment shows the level of the battery.
•
Lightning Bolt Icon: The lightning bolt icon will illuminate when the IEC power cable
is connected to wall power.
•
Bluetooth Icon: The Bluetooth icon will not be lit when Block Rocker Sport is first
powered on (unless it was previously paired with a device). The Bluetooth icon will be
lit solid when a device is paired to Block Rocker Sport.
•
Power Indicator: The power indicator (radio display decimal point) will be lit when
Block Rocker Sport is powered on. The power indicator will not be lit when Block
Rocker Sport is powered off.
9. Master Volume Control: This adjusts the speaker's main mix volume, which includes the
Microphone Input, Auxiliary Input, Radio, and the audio of a paired Bluetooth device.
Rocker Sport is
10
11
1
2
3
10
4
12
8
6
7
9
5
5
