1. General safety instructions

The ROCOOL 600 must be used only by expert personnel certified according to country-specific
standards.
Before first use, read this operating manual thoroughly to prevent improper use.
The ROCOOL 600 must be used only with the refrigerants indicated below. Other gases or fluids
must never be used with the ROCOOL 600.
Do not use or store the unit in environments that are not within the working temperature range.
Protect the ROCOOL 600 from rain or other external liquids.
Never exceed the manifold's maximum pressure of 60 bar. This could irreparably damage the
sensors. There is also a danger of the sight glass breaking, which may injure the user.
During all work, make sure to wear personal protection gear that includes safety gloves and safety
glasses.
Avoid dropping the ROCOOL 600 from big heights
Do not overtighten the valves. This permanently reduces the valves' seal.
Connect only original Rothenberger accessories (external vacuum probe, Red Box) to the ROCOOL
600.

2. Technical data

Pressure display:
Temperature display:
Vacuum display:
Power source:
Monitor (diagonal):
Pressure measurement range:
Precision (at 22°C):
Temperature measurement range:
Working temperature:
Connections:
Max. recording time:
Coolants:
R125, R13, R134a, R141B, R142B, R143, R143A, R152A, R21, R218, R22, R227ea, R23, R290, R32,
R401A, R401B, R401C, R402A, R402B, R403A, R403B, R404A, R405A, R406A, R407A, R407B,
R407C, R407D, R408A, R409A, R410A, R410B, R411A, R411B, R412A, R413A, R414A, R414B,
R415A, R416A, R417A, R420A, R421A, R421B, R422A, R422B, R422C, R422D, R424A, R427A,
R434A, R437A, R438A, R500, R502, R503, R504, R507A, R508A, R508B, R509A, R600, R600A,
R601, R601A, R718, R744 (subcritical).

3. ROCOOL 600 basic functions

1. Open the battery compartment and connect the 9V battery.
2. To turn on the ROCOOL 600, press the power button (1) for 3 seconds. When it starts up, RO
COOL 600 automatically calibrates the sensors to the current zero point.
3. To turn on the backlighting, press the backlight button (3) for 3 seconds.  More current is
required when backlighting is on.
4. To change the settings on the ROCOOL 600, press the set button (4).
• Navigate the settings menu with the up and down arrow keys (2), the set button (4) for confir-
mation, and the Delete key (7) to go to the previous step.
• Not pressing any key for 5 seconds automatically takes you back to the overview screen.
• From the settings menu, you can change the following parameters:
• Refrigerants
• Pressure display
• Temperature display
• Interval of recording
• Ambient temperature display or T2-T1
• T1 / T2 or overheating / undercooling display
bar, psi, KPa, MPa
°C, °F
microns, mbar, mmHg, Pa, mTorr
9V battery, 550 MAh
4 1/3" / 11cm
-1 to 60 bar
+/- 0.5% fs
-50°C – 200°C
-10°C – 50°C
4x ¼" SAE (7/16" UNF)
8h in device, 96h with Red Box
R11, R113, R114, R115, R116, R12, R1234yf, R123A, R124,
