PELI 9480 Mode D'emploi

Catalog #9480
Peli 9480 User Manual
Mast Operation
1. Lift the Light head and pole to a vertical position then slide
the mast down to lock into mount.
2. To collapse the mast, reverse the procedure.
Light Operation
1. Press button on keypad once for high power (default).
2. Press button on keypad to change between high, medium
and low power.
3. Press button on keypad again to switch off.
Note: for performance specifications see Peli.com or peli.com
The 9480 will operate continuously while plugged into AC/mains power.
Flash Mode
1. Press and hold button on keypad for 3 seconds and the light
head will flash. Then select desired power level.
2. Press button on keypad again to switch off.
Bluetooth
This product is equipped with Bluetooth technology which allows you
to control it via an App. It is only compatible with iPhone 4S or later.
To download the App please visit the app store, search under RALS.
Power Pack
The 9480 power pack is removable. This allows continuous use of
the product by replacing it with another fully charged power pack
when required.
Power Pack Level
The power pack is equipped with a power level monitor which
remains permanently illuminated to tell the user how much power
the battery contains. The level monitor will glow brightly when
the product is switched on and dim when not in use.
While the product is switched on, the number of segments
illuminated in the level monitor will gradually reduce over time.
The product will switch off soon after a single red flashing segment
is displayed. Once the product has switched itself off, the single red
segment in the level monitor will continue to flash, indicating that
a recharge is required.
Power Pack Charging
The power pack can be charged inside or outside of the main housing.
1. Remove the dust cap from the charging socket and plug
in the power supply.
2. Connect the power supply to the mains / AC power.
Charge Cycle Indication:
EN
During charging, the level monitor display will become brighter and
continue to cycle until all segments of the display are shown. Once
the display stops cycling and shows all segments, the battery is fully
charged.
NOTE – the power pack can be left attached to the power supply
without any harm to the battery.
WARNING: ONLY USE APPROVED POWER SUPPLY & ENSURE
CHARGING IS CARRIED OUT IN A WELL VENTILATED ROOM.
DO NOT STORE POWER PACKS IN A DISCHARGED STATE. WHEN
NOT IN USE, RECHARGE THE POWER PACK EVERY 3 MONTHS.
Battery/Fuse Replacement
Contact your dealer for a replacement battery or fuse.
Environmental
At the end of its technical life, the sealed lead battery should be sent
to a suitable recycling center or returned to the point of purchase.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation
Battery Safety Information
WARNING: HANDLE AND STORE BATTERIES PROPERLY TO
AVOID INJURY AS DAMAGED BATTERIES CAN BE DANGEROUS!
Most battery issues arise from improper handling of batteries, and
particularly from the use of damaged or counterfeit batteries.
Please review the information below to avoid serious injury and/or
damage to your property.
Rechargeable Batteries
1. Lights should only be charged using the Peli charger that
2. Lights should be charged and operated between the
3. Deep discharge of the rechargeable battery may cause batteries
To remove
the power pack
Always dispose of all batteries properly at an approved battery
simply release
recycling center.
the clips and
lift via the handle.
Manuel de l'utilisateur
pour la Peli 9480
Fonctionnement du mât
1. Soulever la tête d'éclairage et le pôle en position verticale, puis
faire glisser le mât vers le bas pour le verrouiller dans le support.
2. Pour rentrer le mât, inverser la procédure.
Fonctionnement de la lampe
1. Appuyer une seule fois sur le bouton
l'éclairage haute puissance (par défaut).
is supplied with the light.
temperatures shown:
Charge Temperature: -20°C to 50°C (-4°F to 122°F)
Operating Temperature: -20°C to 50°C (-4°F to 122°F)
to vent potentially dangerous gasses and electrolytes.
FR
du clavier pour activer
