Installation; Installing/Replacing The Lamps; Rigging; Operation - EuroLite RFL-3 Mode D'emploi

INSTALLATION

Installing/Replacing the lamps

Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 5 minutes).
During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's
notes!
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device
was not designed for and can destroy the control portion. Damages caused by non-observance are not
subject to warranty.
For the installation, you need 230 V/60 W E-27 lamps.
During the operation, the lamp reaches temperatures of up to 200° C.
Procedure:
Step 1: If replacing the lamp, remove the old lamp from the lamp-socket.
Step 2: Put the new 230 V/60 W E-27 lamp into the socket.

Rigging

When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
Install the device on a plane surface.
This device features a protective insulation.
In general, lighting effects should not be connected to dimming-packs.

OPERATION

Connect the effect to the mains. With the ON/OFF-switch, you can switch the device on and off. The chaser-
speed can be adjusted via the Speed-control. The speed is also sound-controlled. You can adjust the
microphone-sensitivity via the Music-control.
Attention: Remove the wrapping material around the lamps before operating this device!
DANGER TO LIFE!
Only install the lamps with the device switched off!
Unplug from mains before!
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
DANGER OF FIRE!
12/23 00026749.DOC, Version 4.3
