[ RoCon G1 - EHS157056
Intended use
Ÿ
The installation of RoCon G1 Gateway must always be carried out by professional staff who are trained in the installation
and commissioning of electrical devices.
Ÿ
Only operate the device in interior spaces and avoid the influence of humidity, dust as well as insolation and heat radiation.
Any other use which is not described in this installation manual is not an intended use and leads to the exclusion of
warranty and liability. This also applies to conversions and alterations. The device is exclusively intended for private use.
Scope of delivery
RoCon G1 Gateway
Power supply unit Gateway
Mains cable
Documentation
Gateway connections
Picture 1: Connections RoCon G1
Assembly and commissioning
RoCon G1 Gateway can be mounted to the wall or
operating in an upright position. For wall mounting use the
corresponding holding brackets on the casing.
The following sequence must be adhered to during set-up and commissioning:
Connection to RoCon control
During the connection to the RoCon control the Gateway should be switched off. Insert the bus cable supplied into the
corresponding bushing on the side of the Gateway and set up the connection to the RoCon control (see image 3).
Connection to network via LAN
Connect the RoCon G1 Gateway with a router. Insert the network cable into the corresponding specific
Gateway and a free network socket at the installation site. If there is no
can be established using a power
2/24
]
Central Control Unit
5V
Mains cable RoCon control
Brief installation guide
1 Connection of power supply unit
2 LAN network Connection
3 bus connection for RoCon control
4 Status LED
1
2
3
4
LAN adapter. In this case contact a company specialising in network installation.
5 0 m
Picture 2: Wall mounting
LAN network available, often a connection to the router
KA RoCon G1 - EHS157056 . 07/2019 . 008.1550899 00 - EN
m
LAN bushing of the
