6. Attach the front panel to the rear
panel by aligning the magnets and
secure it by tightening the screw
at the bottom left-hand corner
with the included allen key.
7. Use the four M3 x 18 screws to
screw the front panel onto the
back panel.
Page 7
8. Connect keypad cable to the
keypad bezel.
9. Attach the keypad bezel to
the front panel by aligning the
magnets.
10. Connect power AC or PoE+ power source to boot the
iTop OnWall and proceed with setting up your iTop
OnWall using the iOS App „iRoom's iDock"
