Manual AURUS-OLED
Messages & alarms
Sensors (if applicable) – measuring and control
In most cases the AURUS-OLED will have a page, dedicated to sensors (temperature, light,
humidity, wind, ...).
The functions "Messages and Alarms" contain text
messages and/or beep tones which inform that a
certain situation has occurred.
An "ALARM" always has to be deleted manually. Take
care first that the cause of the alarm is taken away. The
alarm is deleted from the different interfaces as
follows below.
A "MESSAGE" disappears automatically after 30
seconds or as soon as a new action occurs on the
particular panel. (A new action can be activating a
function, receiving another message or alarm, etc...)
Snooze = 3 min postponed so you would have time to thumb
through the AURUS-OLED and do whatever is needed to be
done.
Clear/OK = Remove the current ALARM/MESSAGE. Make sure
the cause of the message/alarm has been taken care of, before
pressing ok.! Depending on the kind of alarm, in some cases,
even when the alarm remains present and you click 'OK', the
alarm text may not be displayed again. Clicking 'OK' is only
removing the text, not the cause of it.
Selected sensor + zone: This field shows the selected sensor
zone and displays the measured value in that zone.
The target value of the selected sensor can be set using the
up/down arrows. When you click the up or down arrow, the
measured value displayed will change to the target value.
