Top-hung outward opening window Solar shading
Move the actuator near to the fixing by sliding it on the plates so that the hole in the tracking strip (screwed to the
spindle) matches up with the lateral hole on the fixing.
Fix the spindle to the fixing by using the relevant nut and bolt supplied. Tighten the bolts completely to the plates.
Top-hung outward opening window / Solar shading: Setting the travel. Make the spindle come out by about 10 cm, by connecting the actuator to the
electric supply. Remove the front plastic cover, and then, using a cross-headed screwdriver, also remove the rubber cap.
